• Cisco C9130AXI-G2 switch back with Ethernet ports, power input
1 1

Cisco

Cisco C8130-VAI-G2 | 8100 G2 Router, VDSL2/ADSL ISDN, 4GB DRAM

C8130-VAI-G2

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco 8100 G2 secure router is a compact, fanless small-branch router with an embedded VDSL2/ADSL2+ modem for ISDN-based lines (Annex B/J). It suits small branch and remote sites that need secure routing, such as point-of-sale connectivity, remote workers, IoT and quick deployment for temporary or mobile sites. It is a good fit for ISDN-based DSL markets that also want a fibre WAN option.

The WAN side offers one 1GE RJ-45/SFP combo port, one RJ-11 DSL port and one XGSPON/10G BASE-T port, alongside two 1GE LAN ports and two 1GE flex ports. It delivers 1.9 Gbps forwarding throughput and 1.5 Gbps IPsec throughput (512B), with 4 GB DRAM and 16 GB flash. Power comes from a 66W external adapter, with a typical draw of 23W. The router supports 280K IPv4 routes and 250 IPsec tunnels, and can be mounted on a rack, desktop, under a desk, or on a DIN rail or wall.

It is preloaded with the perpetual Cisco Routing OS Essentials licence and runs in routing mode, requiring IOS XE 26.1.1 or later. SD-WAN operation requires IOS XE 26.2.1. Compatible mounting options include the C8130-G2-RM-19= rack kit, the ACS-1111-DRM= DIN rail kit and the ACS-1100-UDM= under-desk kit.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hardware-accelerated security and networking on a purpose-built SoC
- Fanless design suited to small branch deployments
- Embedded multimode VDSL2/ADSL2+ modem for ISDN-based broadband (Annex B/J)
- XGSPON/10G BASE-T WAN port for high-speed fibre broadband
- Encryption designed to be post-quantum cryptography (PQC) ready
- Zero Trust and SASE-ready architecture with integrated next-generation firewall capabilities
- Flexible management: on-premises, infrastructure-as-code or cloud
- Multiple mounting options: rack, desktop, under-desk and DIN-rail or wall

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- WAN ports: 1x 1GE RJ-45/SFP combo, 1x RJ-11 (DSL), 1x XGSPON/10G BASE-T
- LAN ports: 2x 1GE RJ-45
- Flex ports: 2x 1GE RJ-45
- DSL: Embedded VDSL2/ADSL over ISDN (Annex B/J)
- VDSL2 standard and profiles: ITU G.993.2, profiles 8a, 8b, 8c, 8d, 12a, 12b, 17a and 35b
- ADSL standards: ITU G.992.1 (ADSL), G.992.3 (ADSL2), G.992.5 (ADSL2+)
- Cellular: None
- Forwarding throughput (512B): 1.9 Gbps
- IPsec throughput (512B): 1.5 Gbps
- SD-WAN throughput (512B): 900 Mbps (SD-WAN from IOS XE 26.2.1)
- DRAM / flash: 4 GB / 16 GB
- Console: 1x RJ-45
- Storage and OOB management: 1x USB Type-C 3.0
- IPv4 routes: 280K
- IPv6 routes: 260K
- NAT sessions: 100K
- VRFs: 1K
- IPsec tunnels: 250
- External power supply: 66W, 12 VDC input
- Typical power: 23W
- Dimensions (H x D x W): 1.09 in x 7.8 in x 10.8 in
- Chassis weight: 3.5 lb
- MTBF: over 100,000 hours
- Mounting options: Rackmount, Desktop, Under Desk, DIN-Rail/Wall mount
- Operating temperature: 0 to 40 C at sea level, derate 1 C per 1000 ft above 40 C
- Operating humidity: 5% to 85% relative humidity (non-condensing)
- Operating altitude: 0 to 10,000 ft (0 to 3048 m)

FAQs

Q: What licence does it come with?
A: It is preloaded with the perpetual Cisco Routing OS Essentials licence. Optional upgrades include the perpetual OS Advantage licence, the Routing Advantage term subscription, or Catalyst SD-WAN WAN Essentials and Advantage subscriptions. It does not support the Threat, URL Filtering and Malware Defense add-on licences.

Q: Does it support SD-WAN?
A: It runs in routing mode by default. SD-WAN operation requires IOS XE and SD-WAN Manager 26.2.1. Routing mode requires IOS XE 26.1.1 or later.

Q: How is it powered and does it provide PoE?
A: It uses a 66W external AC adapter with a 12 VDC input and a typical draw of 23W. It does not provide PoE or PoE+ output.

Q: Which DSL standards does the RJ-11 port support?
A: The embedded modem supports VDSL2 (ITU G.993.2, profiles 8a to 35b) and ADSL, ADSL2 and ADSL2+ over ISDN (Annex B/J).

Q: Can I add a cellular module?
A: No. Cellular PIM modules are not supported on this model.

Q: How can it be mounted?
A: It supports rack, desktop, under-desk and DIN-rail or wall mounting. Compatible kits include the C8130-G2-RM-19= rack mount kit, the ACS-1111-DRM= DIN rail kit and the ACS-1100-UDM= under-desk kit.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
