Cisco C1131X-8PWZ | ISR 1100X 8-Port Gigabit Router, Wi-Fi 6, 8GB DRAM

SKU:C1131X-8PWZ

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco ISR 1100X C1131X-8PWZ is a compact, fanless branch router that combines routing, an eight-port Gigabit switch and an embedded Wi-Fi 6 access point in one unit. It suits small branch and remote offices, retail stores, clinics and SOHO sites that want router, switching, wireless and SD-WAN in a single device.

The LAN side provides eight Gigabit Ethernet copper ports, with two Gigabit Ethernet WAN combo ports (copper or SFP). The embedded 802.11ax access point is 2x2 MU-MIMO and uses the Z regulatory domain for Australia and New Zealand. The X model carries 8 GB DRAM and 16 GB flash for app hosting. SD-WAN IPsec throughput reaches up to 650 Mbps, and autonomous-mode IPv4 forwarding reaches up to 1800 Mbps. This SKU has no integrated cellular, so it does not take the LTE-ready PIM variant, which is C1131X-8PLTEPWZ.

It runs a single IOS XE universal image with IP Base as the default, or IOS XE SD-WAN under controller management. Compatible SFPs for the WAN combo ports include GLC-SX-MM, GLC-LH-SM, GLC-T and GLC-TE, and the rack-mount kit is ACS-1100-RM2-19.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Embedded Wi-Fi 6 with OFDMA, MU-MIMO, Target Wake Time and BSS Coloring
- Choice of traditional Cisco IOS XE or controller-managed IOS XE SD-WAN
- Management via WebUI, Cisco DNA Center and Catalyst SD-WAN Manager (vManage)
- On-box security with application-aware NGFW, IPS/IDS, Advanced Malware Protection, URL filtering and Cisco Umbrella SIG
- App-hosting capable with 8 GB DRAM and 16 GB flash
- Fanless, compact form factor with optional rack-mount kit
- Voice support with CUBE and SRST
- Embedded Wireless Controller support for the integrated access point

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- WAN ports: 2 x Gigabit Ethernet combo (copper/SFP)
- LAN ports: 8 x Gigabit Ethernet (copper)
- Wireless LAN: 802.11ax (Wi-Fi 6), embedded access point, 2x2 MU-MIMO
- Wi-Fi domain: Z (Australia, Brazil, New Zealand)
- DRAM / flash: 8 GB / 16 GB
- Cellular: none integrated on this model
- Console: 1 x RJ-45
- USB: 1 x Type A USB 2.0
- SD-WAN IPsec throughput (512B): up to 650 Mbps
- SD-WAN profile throughput (IPsec + QoS + DPI + Flexible NetFlow, 512B): up to 250 Mbps
- SD-WAN overlay tunnels: 200
- IPv4 forwarding throughput (512B, autonomous): up to 1800 Mbps
- IPsec throughput (512B, autonomous): up to 600 Mbps
- Autonomous-mode scale: 100 IPsec SVTI tunnels, 280K IPv4 routes, 100K NAT sessions, 20K firewall sessions, 1K VRFs
- Dimensions (H x W x D): 1.65 x 12.70 x 8.90 in.
- Weight: 4.78 lb (2.17 kg)
- Maximum power consumption: 25 W (excluding power supply loss)
- External power supply: 100-240 VAC, 50-60 Hz, 12 VDC output, max 66 W
- Operating temperature: 0 to 40 C at sea level
- Operating humidity: 10% to 85% RH (non-condensing)
- Minimum supported IOS XE: 17.7.1

FAQs

Q: Does the C1131X-8PWZ need a licence?
A: It runs a single IOS XE universal image with IP Base as the default, and the WebUI needs no licence. Optional technology licences cover Application Experience, Security and IPsec performance. SD-WAN deployments use Cisco DNA Essentials, Advantage or Premier subscriptions through a Smart Account.

Q: Does this router support PoE?
A: PoE and PoE+ are an optional upgrade using the ISR-1100-POE4 module with a 150 W power supply. It provides 4 PoE or 2 PoE+ ports across the 8 LAN ports.

Q: Which SFPs work in the WAN combo ports?
A: Supported SFPs include GLC-SX-MM, GLC-LH-SM, GLC-EX-SMD, GLC-ZX-SM, GLC-T, GLC-TE, SFP-GE-S and SFP-GE-T, along with BX, CWDM and DWDM variants.

Q: How does it differ from C1131X-8PLTEPWZ?
A: This SKU has no integrated cellular. The C1131X-8PLTEPWZ variant adds a pluggable cellular PIM slot for LTE or 5G WAN. Both share the 8 GB DRAM, 16 GB flash and Wi-Fi 6 Z domain hardware.

Q: Can it run SD-WAN?
A: Yes. It supports controller-managed IOS XE SD-WAN with up to 200 overlay tunnels and up to 650 Mbps of SD-WAN IPsec throughput at 512B packets. Minimum supported IOS XE for SD-WAN is 17.7.1.
