Cisco C1126X-8PLTEP | ISR 1100X 8-Port PoE-Capable Router, xDSL/LTE, GE Combo
SKU:C1126X-8PLTEP
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Cisco ISR 1100X C1126X-8PLTEP is a compact, fanless branch router from the ISR 1000 Series. It brings routing, switching, xDSL and cellular WAN together in one device, which suits small branches, remote offices, retail sites and clinics. It can also serve as an SOHO or executive VPN router and supports VoIP survivability with SRST and CUBE.
On the LAN side it provides 8 Gigabit Ethernet copper ports, with optional PoE/PoE+ (4 PoE or 2 PoE+ ports) when paired with the 150W power supply. WAN connectivity covers an integrated VDSL2/ADSL2+ port (Annex B/J), a GE copper/SFP combo port and a pluggable cellular module slot for LTE or 5G options. The X model carries 8 GB DRAM and 8 GB flash for app hosting. It delivers up to 1600 Mbps IPv4 forwarding throughput (512B) in autonomous mode and up to 700 Mbps SD-WAN IPsec throughput. There is no embedded Wi-Fi on this model.
It runs Cisco IOS XE in autonomous or controller-managed SD-WAN mode, with IP Base as the default technology package. Optional Smart Licensing right-to-use packages add Application Experience, Security, Unified Communications and higher IPsec performance. Supported GE SFPs include GLC-SX-MM(D), GLC-LH-SM(D) and GLC-T, and cellular options include the P-LTEA-EA, P-LTEAP18-GL and P-5GS6-GL modules.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Fanless, compact all-in-one router with integrated routing, switching, DSL and cellular WAN options
- Choice of traditional Cisco IOS XE or controller-managed IOS XE SD-WAN
- Optional PoE/PoE+ on LAN ports for powering phones, cameras and access points
- 8 GB DRAM and flash supports app hosting
- Pluggable cellular module for LTE or 5G WAN
- On-box security options including zone-based firewall, IPsec VPN, DMVPN and FlexVPN
- Management through WebUI, Cisco DNA Center and Catalyst SD-WAN Manager
- Smart Licensing with pay-as-you-grow technology packages
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- LAN ports: 8 x Gigabit Ethernet (copper)
- WAN ports: 1 x GE copper/SFP combo, 1 x ADSL2/VDSL2+ (Annex B/J)
- Cellular: 1 x pluggable module slot (LTE CAT4/6/7/18, 5G NSA/SA options)
- PoE: optional, 4 PoE or 2 PoE+ ports, requires 150W power supply
- Memory: 8 GB DRAM / 8 GB flash (X model)
- Wi-Fi: not embedded
- Console: 1 x micro-USB; USB: 1 x Type A USB 3.0
- IPv4 forwarding throughput (512B), autonomous: up to 1600 Mbps
- SD-WAN IPsec throughput (512B): up to 700 Mbps
- SD-WAN overlay tunnels: 200
- IPsec throughput (512B), autonomous: up to 600 Mbps
- IPsec SVTI tunnels: 100
- IPv4 routes: 280K; IPv6 routes: 260K
- NAT sessions: 100K; VRFs: 1K
- VDSL2 profiles: 8a, 8b, 8c, 8d, 12a, 12b, 17a, with vectoring
- Maximum power consumption: 24.6 W (excluding external PS loss)
- Power input: 100-240 VAC, 50-60 Hz; output 12 VDC, 66 W max
- Dimensions (H x W x D): 1.65 x 12.70 x 8.90 in. (approx. 4.2 x 32.3 x 22.6 cm)
- Weight: 4.53 lb (2.05 kg)
- Operating temperature: 0 to 40 C at sea level
- Minimum software: IOS XE 16.11.1 (autonomous), 17.2.1 (SD-WAN)
FAQs
Q: Which licences does the C1126X-8PLTEP use?
A: A single IOS XE Universal image ships with the platform, with IP Base as the default technology package. Optional Smart Licensing packages add Application Experience, Security, Unified Communications and extra IPsec performance. A Smart Account is required for Smart Licensing.
Q: What power supply is needed for PoE?
A: The standard external adapter is 100-240 VAC with a 12 VDC, 66 W output. Optional PoE/PoE+ requires the 150W power supply and the ISR-1100-POE4 adapter, giving 4 PoE or 2 PoE+ ports across the 8 LAN ports.
Q: Which cellular modules work with this router?
A: It accepts pluggable modules including P-LTE-VZ, P-LTE-US, P-LTE-GB, P-LTEA-EA, P-LTEA-LA, P-LTEAP18-GL and P-5GS6-GL. USB LTE dongles D-LTE-NA, D-LTE-GB and D-LTE-AS are also supported.
Q: Which SFPs fit the GE combo WAN port?
A: Supported GE SFPs include GLC-SX-MM(D), GLC-LH-SM(D), GLC-EX-SMD, GLC-ZX-SM(D), GLC-T/TE and SFP-GE-S/T. 100BASE-FX/LX/BX, CWDM and DWDM SFPs are also supported.
Q: Can it run in SD-WAN mode?
A: Yes. It supports controller-managed IOS XE SD-WAN from release 17.2.1, as well as autonomous IOS XE from 16.11.1. SD-WAN mode uses Cisco DNA Essentials, Advantage or Premier subscriptions.
