Juniper

Juniper QFX10016-CHAS | QFX10016 16-Slot Modular Switch Chassis, 96 Tbps

SKU:QFX10016-CHAS

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The QFX10016 is the largest chassis in the Juniper QFX10000 line of modular data centre switches. This 21 U chassis provides 16 line card slots and runs Junos OS, making it a platform for data centre fabric spine and core switching and high-density 100GbE aggregation.

The chassis delivers up to 96 Tbps of system throughput and 32 Bpps of forwarding capacity, with up to 7.2 Tbps per slot and 172.8 Tbps of raw fabric capacity. Fully populated, it scales to 2,304 x 10GbE, 576 x 40GbE or 480 x 100GbE ports. This SKU is the base chassis only, so line cards, switch fabric cards and power supplies are selected separately to suit the deployment. The chassis has 10 power supply bays for AC or DC supplies (not mixed), with a base system typical draw of 3,989 W.

It works with QFX10000 line cards such as the QFX10000-30C-M, QFX10000-60S-6Q and QFX10K-12C-DWDM, along with QFX10016 switch fabric cards, routing control boards, fan trays and fan tray controllers. A midplane-less orthogonal interconnect design and field-replaceable components support long service life.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Midplane-less orthogonal interconnect architecture for system longevity
- Separate dedicated data, control and management planes
- All key components are field-replaceable units
- Redundant control boards, switch fabric cards, fan trays and power supplies
- Supports AC or DC power supplies, not mixed in one chassis
- Open architecture on Junos OS

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Form factor: Modular chassis, 21 U
- Line card slots: 16
- System throughput: Up to 96 Tbps
- Forwarding capacity: Up to 32 Bpps
- Bandwidth per slot: Up to 7.2 Tbps
- Raw fabric capacity: Up to 172.8 Tbps
- Maximum 10GbE port density: 2,304
- Maximum 40GbE port density: 576
- Maximum 100GbE port density: 480
- Fabric redundancy: 5+1
- Control board redundancy: 1+1
- Control board: Intel quad-core 2.5 GHz, 32 GB SDRAM, 50 GB SSD
- Control board ports: 4 x SFP/SFP+ MACsec-capable, RJ-45/SFP management, console, USB 2.0
- Power supply bays: 10 (AC or DC, not mixed)
- Base system typical power: 3,989 W
- Base system reserved power: 5,815 W
- Cooling: Front-to-back airflow, dual hot-swappable fan trays with redundant fans
- Dimensions (W x H x D): 44.2 x 93 x 88.9 cm (17.4 x 36.65 x 35 in)
- Weight (base configuration): 223 kg (491 lbs)
- Weight (redundant configuration): 270 kg (596 lbs)
- Weight (fully loaded chassis): 425 kg (938 lbs)
- Operating system: Junos OS

FAQs

Q: Does the QFX10016-CHAS include line cards, fabric cards or power supplies?
A: No. This SKU is the base chassis only. Line cards, switch fabric cards and power supplies are selected separately, and bundles with fabric cards and power supplies are separate SKUs.

Q: Which line cards work with the QFX10016 chassis?
A: It accepts QFX10000 line cards such as the QFX10000-30C-M, QFX10000-60S-6Q and QFX10K-12C-DWDM.

Q: What power options does the QFX10016 support?
A: It has 10 power supply bays that take AC or DC supplies, but AC and DC cannot be mixed in the same chassis. Base system typical power is 3,989 W and reserved power is 5,815 W, before line cards.

Q: What redundancy does the chassis provide?
A: It supports 5+1 switch fabric redundancy and 1+1 control board redundancy, with dual hot-swappable fan trays and redundant fans.

Q: What are the physical dimensions of the QFX10016?
A: The chassis is 21 U high and measures 44.2 x 93 x 88.9 cm (W x H x D). Weight ranges from 223 kg in the base configuration to 425 kg fully loaded.
