Cisco UCSX-FI-6454-U | UCS 6454 54-Port 10/25G Fabric Interconnect, UCSM
SKU:UCSX-FI-6454-U
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The UCS 6454 is a 1RU top-of-rack fabric interconnect from the Cisco UCS 6400 Series. It provides the connectivity and management backbone for a UCS domain, linking B-Series blades, UCS-managed C-Series rack servers, S-Series storage servers and X-Series chassis over unified Ethernet, FCoE and Fibre Channel.
This standalone SKU offers 48 x 10/25-Gbps SFP28 ports, 16 of which are unified ports that can run 10/25 GbE or 8/16/32G Fibre Channel, plus 6 x 40/100-Gbps QSFP28 uplink ports. Each 40/100G port can break out to 4 x 10/25G. Switching throughput is 3.82 Tbps, with Layer 2 hardware forwarding at 1.2 bpps. It is managed through Cisco UCS Manager and includes port licences for 18 x 10/25-Gbps and 2 x 40/100-Gbps ports. Additional port licences are ordered separately.
It works with UCS 2204, 2208 and 2408 IOM/FEX modules and VIC 1455, 1457 and 1467 adapters. Power is supplied by two PSU slots, filled with UCS-PSU-6332-AC (650 W) or UCS-PSU-6332-DC (930 W) units. Airflow is front-to-back with hot-swappable fans.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Cut-through, low-latency, line-rate 10/25/40/100 GbE architecture
- FCoE support on all Ethernet ports
- Unified ports can run Fibre Channel at 8/16/32G
- 40/100G ports break out to 4 x 10/25G
- 200 Gbps bandwidth to the 2408 IOM/FEX per 5108 chassis
- Out-of-band and in-band management through UCS Manager
- L1/L2 ports for high-availability pairing of two fabric interconnects
- Front-to-back airflow with hot-swappable fans and PSUs
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Form factor: 1RU
- Ports: 48 x 10/25-Gbps SFP28 and 6 x 40/100-Gbps QSFP28
- Unified ports: 16 (10/25 GbE or 8/16/32G Fibre Channel)
- Downlink speeds: 1/10/25-Gbps Ethernet/FCoE, 8/16/32-Gbps Fibre Channel
- 40/100-Gbps ports: 6 (ports 49-54), breakout to 4 x 10/25G
- Switching throughput: 3.82 Tbps
- Layer 2 forwarding: 1.2 bpps
- MAC address table entries: 32,000
- Port licences included: 18 x 10/25-Gbps and 2 x 40/100-Gbps
- Fan modules: 3+1 redundancy, hot swappable
- Management ports: 10/100/1000 management, console, USB, L1/L2 HA
- CPU: Intel Xeon D-1528 v4 1.6 GHz, 64 GB RAM, 8 MB NVRAM, 128 GB SSD bootflash
- Power supply slots: 2 (UCS-PSU-6332-AC 650 W or UCS-PSU-6332-DC 930 W)
- Dimensions (H x W x D): 4.4 x 43.9 x 57.1 cm
- Weight: 10.10 kg with two power supplies, two expansion modules and fans
- Operating temperature: 0 to 40 C
- Non-operating temperature: -40 to 70 C
- Humidity (non-condensing): 5 to 95%
- Altitude: 0 to 3000 m
- Supported IOM/FEX: UCS 2204, 2208, 2408
FAQs
Q: What licensing does this fabric interconnect include?
A: It includes port licences for 18 x 10/25-Gbps and 2 x 40/100-Gbps ports. Additional port licences are ordered separately.
Q: What power supplies does it use?
A: It has two PSU slots. Fit UCS-PSU-6332-AC (650 W, 100-240 VAC) or UCS-PSU-6332-DC (930 W, -48 VDC) units.
Q: Which IOM and FEX modules does it support?
A: It supports the UCS 2204, 2208 and 2408 IOM/FEX modules for connecting UCS blade chassis.
Q: How is it managed?
A: It is managed with Cisco UCS Manager, typically deployed as an active/passive cluster using the L1/L2 high-availability ports.
Q: Can the 40/100G ports be used for 10/25G connections?
A: Yes. Each of the six 40/100-Gbps QSFP28 ports can break out to 4 x 10/25G.
