Cisco UCS-FI-6536-U | UCS 6536 36-Port 100G Fabric Interconnect, UCSM
SKU:UCS-FI-6536-U
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Cisco UCS 6536 is a 1RU fabric interconnect from the UCS 6500 Series. It forms the core of a Cisco UCS domain, giving UCS X-Series, B-Series blade, C-Series rack and S-Series storage servers unified LAN and SAN connectivity under a single management domain. This SKU is the UCS Manager (UCSM) managed version.
The 6536 provides 36 unified 40/100-Gbps QSFP28 ports, each able to break out to 4x10/25G Ethernet or 4x8/16/32G Fibre Channel. Switching capacity is 7.42 Tbps per fabric interconnect (14.84 Tbps per unified fabric domain) with a Layer-2 forwarding rate of 2.4 billion packets per second. It carries Ethernet, FCoE and Fibre Channel traffic with cut-through, low-latency forwarding, and uses 32 GB of system memory and a 4-core CPU.
The chassis takes up to two 1100W AC power supplies (UCS-PSU-6536-AC) in a 1+1 redundant arrangement and six fans (UCS-FAN-6536). UCSM support requires UCS release 4.2(3) or later. It works with UCSX-9508 and UCSB-5108 chassis, UCSX-9108-25G and UCSX-9108-100G IFMs, and VIC 1300, 1400/14000 and 15000 series adapters, using Cisco 10/25/40/100G QSFP28 optics and cables.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Cut-through, low-latency architecture with predictable latency regardless of packet size
- Unified fabric consolidating LAN and SAN traffic (FC, FCoE, iSCSI, NFS, NVMe-oF)
- Unified ports run 10/25/40/100G Ethernet or break out to four 8/16/32G Fibre Channel ports
- Ethernet and Fibre Channel switch mode and end-host mode
- Priority-based Flow Control (802.1Qbb), ETS (802.1Qaz) and DCBX
- QinQ forwarding and VIC QinQ tunnelling
- Hot-swappable 1+1 redundant PSUs and fans with dual-rotor redundancy
- Hosts Cisco UCS Manager in an active/passive cluster over redundant fabric interconnects
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Ports: 36 x 40/100-Gbps QSFP28 unified ports
- Breakout: 4x10/25G Ethernet or 4x8/16/32G Fibre Channel
- Supported speeds: 1/10/25/40/100-Gbps Ethernet/FCoE, 8/16/32-Gbps Fibre Channel
- Switching capacity: 7.42 Tbps per FI, 14.84 Tbps per unified fabric domain
- Layer-2 forwarding rate: 2.4 bpps
- MAC address table entries: 32,000
- VLANs: 3K
- Jumbo frames: up to 9216 bytes
- Hardware queues: 16 per port (FCoE plus five user-defined)
- CPU: 4 cores
- System memory: 32 GB
- Management ports: L1, L2, RJ-45 Management, RS-232 Serial
- USB ports: 1
- Power supplies: up to 2 x 1100W AC, 1+1 redundant
- Typical operating power: 348 W
- Maximum power: 800 W
- Input voltage (AC): 100 to 240 VAC
- Input voltage (DC): -40 to -72 VDC
- Fans: 6, hot swappable
- Airflow: front (PSU/fan side) to back (port-side exhaust)
- Dimensions (H x W x D): 4.4 x 43.9 x 62.7 cm
- Operating temperature: 0 to 40 C
- Weight: 11.6 kg with two power supplies and six fans
- RoHS compliance: Yes
FAQs
Q: Is this the UCS Manager or Intersight Managed Mode version?
A: UCS-FI-6536-U is the UCS Manager (UCSM) version. The Intersight Managed Mode version is a separate SKU, UCSX-FI-6536-U.
Q: What power supplies does the 6536 use?
A: It takes up to two UCS-PSU-6536-AC 1100W AC power supplies in a 1+1 redundant arrangement. Typical draw is 348 W and maximum draw is 800 W.
Q: Which fans does it use?
A: The 6536 uses six hot-swappable fans, part number UCS-FAN-6536, with dual-rotor redundancy.
Q: Which UCS software release is required?
A: UCS Manager support requires UCS release 4.2(3) or later. X-Series M6 and M7 servers managed in UCSM need release 4.3(2).
Q: Which chassis and adapters does it work with?
A: It supports UCSX-9508 and UCSB-5108 chassis, UCSX-9108-25G and UCSX-9108-100G IFMs, IOM 2304 and 2408, and VIC 1300, 1400/14000 and 15000 series adapters.
Q: Can the ports carry Fibre Channel as well as Ethernet?
A: Yes. The unified QSFP28 ports can run 10/25/40/100G Ethernet and FCoE, or break out to four 8/16/32G Fibre Channel ports.
