Cisco UCS-FI-6536-D-U | UCS 6536 36-Port 40/100G Fabric Interconnect, UCSM
SKU:UCS-FI-6536-D-U
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The UCS 6536 is a 1RU fabric interconnect from the Cisco UCS 6500 Series, built for the core of a Cisco UCS domain. It carries LAN, SAN and management traffic on one unified fabric and connects X-Series, B-Series blade, C-Series rack and S-Series storage servers. This -D SKU runs in UCS Manager (UCSM) mode and is the ordering PID for UCS M7-generation servers.
It provides 36 x 40/100G QSFP28 ports with 7.42 Tbps of switching throughput and a forwarding rate of 2.4 billion packets per second. Four unified ports (33-36) support 40/100G Ethernet or Fibre Channel breakout, and all 36 ports can break out to 10/25G for up to 144 x 10/25G connections. Two 1100W AC hot-swap power supplies and six fan modules provide 1+1 power redundancy and front-to-back cooling. It ships with a perpetual software licence that activates all ports and features.
It works with UCSX-9508 and UCSB-5108 chassis, UCSX-9108-25G and UCSX-9108-100G IFMs, 2304 and 2408 IOMs, and Cisco VIC 1300, 1400 and 15000 series adapters. UCSM support requires UCS release 4.2(3) or later, and X-Series M6/M7 servers under UCSM need release 4.3(2).
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Line-rate, low-latency, lossless 10/25/40/100G Ethernet, Fibre Channel, NVMe over Fabric and FCoE
- Cut-through architecture with latency under 1 microsecond
- Unified fabric consolidating LAN and SAN traffic
- Hosts Cisco UCS Manager in a highly available active/passive cluster
- Ethernet and Fibre Channel switch and end-host modes
- Priority Flow Control (802.1Qbb), ETS (802.1Qaz) and DCBX
- 1+1 power redundancy and fan rotor-level redundancy
- Scales to 20 blade chassis via fabric extender architecture
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Form factor: 1RU
- Ports: 36 x 40/100-Gbps QSFP28
- Supported speeds: 1/10/25/40/100G Ethernet/FCoE; 8/16/32G Fibre Channel
- Unified ports: 4 (ports 33-36)
- Maximum 10/25G Ethernet ports: 144 (after breakout)
- Maximum 8/16/32G FC ports: 16 (after breakout of ports 33-36)
- Throughput: 7.42 Tbps (14.84 Tbps per unified fabric domain)
- Forwarding rate: 2.4 billion packets per second
- MAC address table entries: 32,000
- Jumbo frames: up to 9216 bytes
- CPU: 4 cores
- System memory: 32 GB
- Management ports: L1, L2, RJ-45 Management, RS-232 Serial
- USB ports: 1
- Power supplies: up to 2 x 1100W AC
- Typical operating power: 348 W
- Maximum power (AC): 800 W
- Input voltage (AC): 100 to 240 VAC, 50 to 60 Hz
- Fans: 6 hot-swappable modules
- Airflow: front (PSU/fan-side) to back (port-side exhaust)
- Dimensions (H x W x D): 4.4 x 43.9 x 62.7 cm
- Weight: 11.6 kg with two PSUs and six fans
- Operating temperature: 0 to 40 C
- Humidity: 5 to 95%
- RoHS compliance: Yes
FAQs
Q: Does it need a separate software licence?
A: No licence management is needed. It ships with a perpetual software licence (UCS-FI-6500-SW) that activates all ports and software features.
Q: What management mode does this SKU run in?
A: It runs in Cisco UCS Manager (UCSM) mode. It is the -D ordering PID for UCS M7-generation servers and has no functional difference from the non-D UCS-FI-6536-U.
Q: What power does it need?
A: It uses up to two UCS-PSU-6536-AC-D 1100W Platinum AC supplies (100-240VAC) for 1+1 redundancy. Typical draw is 348 W and maximum is 800 W. Two identical AC power cords are selected separately.
Q: Which servers, chassis and adapters does it work with?
A: It supports UCSX-9508 and UCSB-5108 chassis, X-Series M6/M7, B-Series M4/M5/M6, C-Series M4/M5/M6/M7 and S-Series M5 servers, and Cisco VIC 1300, 1400 and 15000 series adapters. UCSM support requires UCS release 4.2(3) or later.
Q: Which optics and cables does it support?
A: It supports QSFP-40G and QSFP-100G transceivers (SR4, LR4, SR-BiDi, CWDM4-lite, SL4, DR), QSA and QSA28 adapters, and breakout cables. S-Class transceivers do not support FCoE.
