Cisco UCS-FI-6536-D | UCS 6536 36-Port 40/100G QSFP28 Fabric Interconnect
SKU:UCS-FI-6536-D
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The UCS 6536 is a 1RU fabric interconnect from the Cisco UCS 6500 Series, built to sit at the core of a Cisco UCS domain. It converges LAN and SAN traffic over a single fabric and provides connectivity and management for UCS X-Series, B-Series and C-Series servers in the data centre.
The UCS-FI-6536-D delivers 36 x 40/100G QSFP28 ports with support for 1/10/25/40/100G Ethernet and FCoE, plus 8/16/32G Fibre Channel on four Unified Ports (33-36). Switching performance is 7.42 Tbps per fabric interconnect, with breakout supported on all 36 ports and a maximum of 128 server ports after breakout. This is the UCS Manager (UCSM) managed variant, and the -D suffix is the ordering PID for UCS M7 servers, functionally identical to the non-D part. It includes the UCS-FI-6500-SW perpetual licence, which activates all ports and software features.
The unit uses two hot-swappable 1100W AC power supplies and six hot-swappable fans, with front-to-back airflow. It works with UCS X-Series M6/M7, B-Series M4/M5/M6, C-Series M4/M5/M6/M7 and S-Series M5 servers, VIC 1400/14000/15000 adapters and the X9108-IFM-100G, and supports QSA/QSA28 adapters for 1/10/25G connectivity.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Line-rate, low-latency, lossless 10/25/40/100G Ethernet, FCoE and Fibre Channel with a cut-through architecture
- Unified fabric converges LAN and SAN traffic, reducing NICs, HBAs, switches and cables
- All 36 ports support breakout and QSA/QSA28 adapters for 1G/10G/25G connectivity
- Redundant hot-swappable fans and power supplies for high availability
- End-to-end system latency under 1 microsecond
- Enables 1600Gbps bandwidth per X9508 chassis with the X9108-IFM-100G
- Scales to 20 chassis using fabric extender architecture
- Priority Flow Control (802.1Qbb) and enhanced transmission selection QoS
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Ports: 36 x 40/100-Gbps QSFP28
- Supported speeds: 1/10/25/40/100-Gbps Ethernet/FCoE; 8/16/32-Gbps Fibre Channel
- Unified ports: 4 (ports 33-36)
- Switching performance: 7.42 Tbps per fabric interconnect
- Breakout: supported on all 36 ports, maximum 128 server ports after breakout
- CPU: 4 cores
- System memory: 32 GB
- Management ports: L1, L2, RJ-45 Management, RS-232 Serial
- USB ports: 1
- Management software: UCS Manager (UCSM)
- Power supplies (up to 2): 1100W AC, hot-swappable
- Typical operating power: 348 W
- Maximum power: 800 W
- Input voltage (AC): 100 to 240 VAC
- Input voltage (DC): -40 to -72 VDC
- Fans: 6, variable speed, hot-swappable
- Airflow: front (PSU/fan-side) to back (port-side exhaust)
- Dimensions (H x W x D): 4.4 x 43.9 x 62.7 cm (1.72 x 17.3 x 24.7 in)
- Weight: 11.6 kg (25.5 lb) with two power supplies and six fans
- Operating temperature: 0 to 40 C
- Humidity: 5 to 95%
- Altitude: 0 to 4000 m
FAQs
Q: Does the UCS-FI-6536-D need a separate software licence?
A: No. It ships with the UCS-FI-6500-SW perpetual licence, which activates all ports and software features of the 6500 series fabric interconnect.
Q: What is the difference between the UCS-FI-6536-D and the non-D part?
A: The -D suffix is the ordering PID for UCS M7 servers. It is functionally identical to the non-D version. This SKU is the UCS Manager (UCSM) managed variant.
Q: Which servers and adapters does it work with?
A: It works with UCS X-Series M6/M7, B-Series M4/M5/M6, C-Series M4/M5/M6/M7 and S-Series M5 servers, VIC 1400/14000/15000 adapters and the X9108-IFM-100G.
Q: Which ports support Fibre Channel?
A: Fibre Channel at 8/16/32G is available on the four Unified Ports (33-36) using breakout.
Q: What power does it use?
A: It takes up to two hot-swappable 1100W AC power supplies (100 to 240 VAC), with typical consumption of 348 W and a maximum of 800 W. It does not provide PoE.
