• Cisco N9K-C93180YC-FX3H 25G switch with SFP28 ports and QSFP28 uplinks
1 1

Cisco

Cisco N9K-C93180YC-FX3H | Nexus 9300-FX3 24-Port 1/10/25G Switch, 6x 40/100G QSFP28, MACsec

N9K-C93180YC-FX3H

POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Cisco Nexus 93180YC-FX3H is a high-performance 1RU data center switch designed for cost-effective cloud-scale deployments and enterprise environments. With 24 licensed ports supporting 1/10/25 Gbps speeds and 6 uplink ports capable of 40/100 Gbps, it delivers wire-rate security, MACsec encryption, and precise timing through SyncE and PTP boundary clock functionality. Built on Cisco Cloud Scale technology, this switch is ideal for telco data center edge deployments, spine-leaf architectures, and virtualized environments requiring flexible Layer 2 and Layer 3 scalability.

Features

Layer 2 and Layer 3 switching with flexible scalability
- Wire-rate MACsec encryption for secure data transmission
- SyncE and PTP boundary clock for precise timing synchronization
- Support for VXLAN and EVPN for network virtualization
- Real-time streaming telemetry for network analytics and monitoring
- Programmable automation via NX-API and Python scripting
- Dual redundant power supply support for high availability
- Port-side intake/exhaust airflow options for flexible cooling
- Cloud Scale ASIC technology for wire-rate performance
- Support for Cisco ACI and standalone NX-OS modes
- Comprehensive routing protocols: BGP, OSPF, EIGRP, IS-IS
- Advanced QoS and traffic management capabilities
- Large buffer architecture for burst traffic handling
- Hot-swappable fan modules and power supplies
- Out-of-band management via dedicated management port

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

Form Factor: 1RU fixed-configuration switch
- Downlink Ports: 24 x 1/10/25 Gbps SFP28 (licensed to use 24 of 48 physical ports)
- Uplink Ports: 6 x 40/100 Gbps QSFP28
- Switching Capacity: 3.6 Tbps
- Forwarding Rate: 1.2 Bpps (billion packets per second)
- Latency: Sub-microsecond (approximately 1 microsecond)
- MAC Address Table: 128,000 entries
- VLAN Support: Up to 4,096 VLANs
- Jumbo Frame Support: Up to 9,216 bytes
- Power Consumption: Typical 375W, Maximum 600W
- Power Supply Options: Dual redundant (NXA-PAC-650W, NXA-PDC-930W, N9K-PUV-1200W)
- Security: MACsec encryption (wire-rate)
- Timing: SyncE and PTP boundary clock support
- Management: CLI, SNMP, NX-OS, Cisco ACI support
- Operating System: NX-OS 10.3.1 or above required
- Dimensions: Standard 1RU rack-mountable
- Weight: Approximately 12 lbs (5.4 kg)
- Airflow: Port-side intake or exhaust options available

FAQs

Q: What is the difference between the FX3H and standard FX3 models?
A: The FX3H variant includes hardware-based licensing that restricts usage to 24 of the 48 physical SFP28 ports, making it a more cost-effective option for deployments that do not require the full 48-port density. It also includes MACsec and SyncE support optimized for telco edge environments.

Q: What NX-OS version is required for this switch?
A: The Nexus 93180YC-FX3H requires NX-OS version 10.3.1 or higher. It is important to verify software compatibility before deployment to ensure full feature support.

Q: Can this switch be used in both ACI and NX-OS mode?
A: Yes, the Nexus 93180YC-FX3H supports both Cisco ACI fabric mode and standalone NX-OS mode, providing flexibility for data center automation and traditional network deployments.

Q: What are the typical use cases for this switch?
A: This switch is ideal for data center leaf layer deployments, telco data center edge environments requiring precise timing with SyncE and PTP, spine-leaf architectures, and virtualized environments needing multi-rate 1/10/25G server connectivity with 40/100G uplinks.

Q: Does this switch support PoE?
A: No, the Nexus 93180YC-FX3H does not support Power over Ethernet. It is designed as a fiber-based data center switch with SFP28 and QSFP28 optical ports.
