• Cisco N9K-C93180YC-EX-24 switch with 24x 1/10/25G SFP28 ports
1 1

Cisco

Cisco N9K-C93180YC-EX-24 | Nexus 9300-EX 24-Port 1/10/25G Switch, 6x 40/100G QSFP28

N9K-C93180YC-EX-24

POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Cisco N9K-C93180YC-EX-24 is a compact 1RU data center leaf switch designed for high-density spine-leaf architectures. With 24 licensed ports supporting 1/10/25G speeds and 6x 40/100G QSFP28 uplinks, it delivers 3.6 Tbps switching capacity and sub-microsecond latency for demanding data center workloads. Ideal for top-of-rack deployments requiring multi-speed fiber or DAC connectivity, it supports both standalone NX-OS and ACI deployment modes with VXLAN EVPN for scalable Layer 2 overlays.

Features

24 licensed SFP28 ports (of 48 total) supporting 1/10/25-Gbps Ethernet with flexible speed negotiation
- 6x QSFP28 uplinks supporting 40/100-Gbps or mixed-speed configurations (10/25/40/50/100G)
- Cloud Scale ASIC architecture for wire-rate performance and low-latency switching
- VXLAN and EVPN support for scalable Layer 2 overlay networks and multi-tenancy
- Virtual PortChannel (vPC) technology for Layer 2 multipathing and redundancy
- Comprehensive Layer 3 routing: OSPF, EIGRP, BGP, RIPv2, PIM-SM, SSM, MSDP
- Advanced QoS and traffic management with granular policy controls
- Hot-swappable redundant power supplies and fans for high availability
- In-Service Software Upgrade (ISSU) for non-disruptive maintenance
- Telemetry and analytics support including Cisco Tetration integration
- FC-FEC forward error correction for 25G optical and DAC connectivity
- Flexible deployment: standalone NX-OS or Cisco ACI leaf mode
- Comprehensive management: CLI, SNMP, API/REST, telemetry streaming
- Jumbo frame support up to 9216 bytes
- Advanced security features including access control lists (ACLs) and MACsec encryption readiness

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

Total Ports: 48-port chassis with 24-port license (any 24 ports active)
- Downlink Ports: 24x 1/10/25-Gbps SFP28
- Uplink Ports: 6x 40/100-Gbps QSFP28
- Switching Capacity: 3.6 Tbps
- Forwarding Rate: 2.6 billion packets per second (bpps)
- Latency: Sub-1 microsecond
- CPU: 4-core processor
- Memory: 24 GB system memory
- Storage: 64 GB SSD
- Buffer: 40 MB system buffer
- MAC Address Table: Up to 512,000 entries
- Management Ports: 1x RJ-45 console, 1x SFP management port
- USB Ports: 1x USB
- Power Supply: Dual hot-swappable (650W AC, 930W DC, or 1200W HVAC/HVDC options)
- Typical Power Consumption: 210W
- Maximum Power Consumption: 470W
- Form Factor: 1RU rack-mountable
- Airflow: Front-to-back or back-to-front (model dependent)
- Operating System: Cisco NX-OS
- Certifications: AS/NZS 60950-1, IEC 60950-1, EN 60950-1, UL 60950-1, EN 55022 Class A, CISPR 22 Class A, RoHS compliant

FAQs

Q: What is the difference between N9K-C93180YC-EX-24 and N9K-C93180YC-EX?
A: The N9K-C93180YC-EX-24 comes with a 24-port license allowing any 24 of the 48 physical downlink ports to be active. The standard N9K-C93180YC-EX has all 48 ports licensed and active. You can upgrade the -24 model to 48 ports by purchasing the N9K-EX-24P-UPG= upgrade license.

Q: Can this switch be used in Cisco ACI fabrics?
A: Yes, the N9K-C93180YC-EX-24 supports both standalone NX-OS mode and Cisco Application Centric Infrastructure (ACI) as a leaf switch. It provides hardware support for VXLAN EVPN overlays, making it ideal for modern data center automation and policy-driven networking.

Q: What licensing is required for Layer 3 routing features?
A: The switch requires a minimum of Network Essentials license for LAN Base features. Advanced routing protocols like OSPF, BGP, EIGRP, and multicast require additional licenses such as Network Advantage or higher tiers.

Q: Is this switch suitable for top-of-rack deployments?
A: Yes, the N9K-C93180YC-EX-24 is specifically designed for data center top-of-rack and leaf-spine architectures. Its multi-speed 1/10/25G downlinks provide flexible server connectivity, while 40/100G uplinks ensure high-bandwidth aggregation layer connectivity.

Q: What is the end-of-sale status for this model?
A: Cisco announced end-of-sale for the N9K-C93180YC-EX-24 in August 2022. The recommended replacement is the N9K-C93180YC-FX3 series, which offers similar capabilities with updated hardware. Pre-owned and refurbished units remain available through authorized resellers.
