• Cisco N3K-C3524P-10GX silver switch with 24x10G SFP+ ports
1 1

Cisco

Cisco N3K-C3524P-10GX | Nexus 3500 24-Port 10G SFP+ Switch, Ultra-Low Latency

N3K-C3524P-10GX

POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Cisco N3K-C3524P-10GX Nexus 3524-X is a high-performance 1RU data center switch delivering 24 active 10G SFP+ ports with industry-leading sub-200ns latency via Algo Boost technology. Designed for top-of-rack deployments, high-frequency trading, and HPC environments, it provides line-rate Layer 2/3 switching with 480 Gbps capacity and 360 Mpps forwarding performance. The switch is expandable to 48 ports via license upgrade and features dual hot-swappable power supplies for mission-critical reliability.

Features

Cisco Algorithm Boost (Algo Boost) technology for sub-200ns latency
- Line-rate Layer 2 and Layer 3 switching on all ports
- VXLAN overlay support with BGP EVPN for multi-tenant data centers
- Virtual Port Channel (vPC) for redundant uplinks without STP blocking
- Virtual Device Context (VDC) for logical switch partitioning
- IEEE 1588v2 Precision Time Protocol (PTP) for nanosecond-level time sync
- 1-PPS (Pulse-Per-Second) output for external time synchronization
- Latency monitoring and visibility tools for real-time performance analysis
- Switched Port Analyzer (SPAN) and Encapsulated Remote SPAN (ERSPAN)
- In-Service Software Upgrade (ISSU) for non-disruptive updates
- Hot-swappable power supplies and fan modules for high availability
- Comprehensive QoS with 8 egress queues and dynamic buffer allocation
- Cisco TrustSec security with MACsec encryption support
- Fabric Extender (FEX) support for simplified management
- REST API and Python scripting for automation and programmability
- Cisco Data Center Network Manager (DCNM) integration
- Support for both forward and reversed airflow configurations

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

24 x 10G SFP+ ports (1/10 Gbps), expandable to 48 ports via license
- Switching capacity: 480 Gbps
- Forwarding rate: 360 million packets per second (Mpps)
- Ultra-low latency: <200 nanoseconds with Algo Boost technology
- Layer 2 and Layer 3 line-rate switching
- MAC address table: up to 64,000 entries
- 1 x 10/100/1000 Mbps management port
- 1 x RS-232 console port, 2 x USB ports
- 1 x 1-PPS timing port (RF1.0/2.3 QuickConnect)
- Dual redundant hot-swappable AC/DC power supplies
- Four hot-swappable fan modules
- Form factor: 1RU rack-mountable
- Dimensions (H x W x D): 4.36 x 43.9 x 46.7 cm (1.72 x 17.3 x 18.38 in)
- Weight: 7.9 kg (17.4 lb)
- Typical power consumption: 102W, Maximum: 193W
- Jumbo frames: up to 9216 bytes MTU
- Operating system: Cisco NX-OS
- Airflow: Front-to-back or back-to-front options

FAQs

Q: Does the N3K-C3524P-10GX support Power over Ethernet (PoE)?
A: No, the N3K-C3524P-10GX is a pure 10 GbE fiber/copper switch optimized for high-density 10 Gbps connectivity and does not support PoE. It is designed for data center server and storage connectivity.

Q: Can I expand the switch from 24 to 48 ports?
A: Yes, the N3K-C3524P-10GX has 48 physical SFP+ ports on the hardware, with 24 ports enabled by default. You can upgrade to enable all 48 ports through a Cisco port expansion license.

Q: What makes this switch suitable for high-frequency trading and HPC environments?
A: The N3K-C3524P-10GX features Cisco Algo Boost technology delivering ultra-low latency of less than 200 nanoseconds, precision timing with IEEE 1588 PTP support, and a 1-PPS timing port. These capabilities are critical for time-sensitive applications in financial trading and HPC clusters.

Q: Does this switch support 40G connectivity?
A: Yes, the Nexus 3500 platform can achieve 40 Gigabit Ethernet by combining four sequential SFP+ interfaces into a logical 40G port using breakout functionality and appropriate cabling. This requires configuration via NX-OS commands.

Q: What routing protocols are supported on the N3K-C3524P-10GX?
A: The switch supports industry-standard Layer 3 routing protocols including OSPF, BGP, EIGRP, RIP, VRF-Lite, VRRP, and PIM. It also supports VXLAN routing, Virtual Device Context (VDC), and vPC for advanced data center deployments.
