• Cisco Nexus 9018 switch with black silver faceplate and ports
1 1

Cisco

Cisco N3K-C3172TQ-ZV | Nexus 3100 48-Port 10GBASE-T Switch, 6x 40G QSFP+, Layer 3

N3K-C3172TQ-ZV

POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Cisco Nexus 3172TQ is a high-performance data center switch delivering 1.4 Tbps switching capacity and 1 billion packets per second throughput in a compact 1RU form factor. Designed for top-of-rack deployments, it features 48 10GBASE-T ports and 6 QSFP+ uplinks, supporting comprehensive Layer 2 and Layer 3 routing protocols including BGP, OSPF, and EIGRP. Built on Cisco NX-OS, it offers flexible airflow options and redundant power for mission-critical environments.

Features

Layer 2 and Layer 3 switching with wire-rate performance on all ports
- Virtual Port Channel (vPC) technology for Layer 2 multipathing and elimination of Spanning Tree Protocol
- 64-way Equal-Cost Multipath (ECMP) routing for Layer 3 fat-tree designs
- Support for VXLAN and BGP EVPN (NX-OS 7.0(3)I4(1) and later)
- Comprehensive Quality of Service (QoS) with support for up to 4,096 VLANs
- Cisco Nexus Data Broker for network test access point (TAP) or SPAN aggregation
- Low-latency architecture based on Broadcom StrataXGS Trident II chipset
- Flexible deployment with AC or DC power supply options
- Hot-swappable redundant power supplies and fans
- Advanced security features including port security and access control lists
- Management via CLI, web interface, SNMP, and system event logging
- Support for both forward and reverse airflow configurations
- Line-rate traffic throughput for both Layer 2 and Layer 3 operations

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

48x 10GBASE-T RJ-45 ports (supports 100Mbps, 1Gbps, and 10Gbps)
- 6x QSFP+ ports (each supports 4x 10GbE or 1x 40GbE)
- Switching capacity: 1.4 Tbps
- Forwarding rate: Up to 1 billion packets per second (bpps)
- System memory: 4GB RAM
- Dual-core 2.5GHz x86 CPU
- MAC address table: Up to 288,000 entries
- Jumbo frame support: Up to 9,216 bytes MTU
- Form factor: 1RU rackmount
- Redundant hot-swappable power supplies (2x)
- Redundant fans (3+1 configuration)
- Management: 1x console, 1x management port, 1x USB
- Airflow options: Port-side exhaust or port-side intake
- Power consumption: Typical 360W
- Dimensions (H x W x D): 4.4 x 43.9 x 50.5 cm
- Weight: 10 kg
- Operating system: Cisco NX-OS

FAQs

Q: What is the difference between the N3K-C3172TQ-ZV and other 3172TQ models?
A: The N3K-C3172TQ-ZV is the base Nexus 3172TQ model with 4GB of memory and support for 48 10GBASE-T ports. The -XL variant includes 8GB memory for object-model programming, while the -32T variant ships with only 32 ports enabled by default, requiring a license upgrade for the remaining 16 ports.

Q: Can this switch operate in both Nexus 3000 and Nexus 9000 modes?
A: Yes, the Nexus 3172TQ can operate in either N3K mode or N9K mode. In N9K mode, the switch follows the Nexus 9000 licensing model, where the N3K-LAN1K9 license is required for Layer 3 features instead of the N3K-BAS1K9 license used in N3K mode.

Q: What Layer 3 routing protocols are supported?
A: The switch supports comprehensive Layer 3 unicast and multicast routing including BGP, OSPF, EIGRP, RIPv2, PIM-SM, SSM, and MSDP. Full Layer 3 features require appropriate licensing depending on the operating mode.

Q: Is this switch suitable for top-of-rack deployment?
A: Yes, the Nexus 3172TQ is specifically designed as a cost-effective, power-efficient line-rate Layer 2 and 3 top-of-rack switch for data center environments. It delivers wire-rate performance on all ports and supports virtual port-channel technology for Layer 2 multipathing.

Q: What is the end-of-life status for this model?
A: Cisco announced end-of-sale and end-of-life for the N3K-C3172TQ series in October 2021. While the switch is no longer sold new by Cisco, it remains a viable solution for existing deployments and is widely available through the secondary market with extended third-party support options.
