• Cisco Catalyst 9300 Switch with Multiple Gigabit Ethernet Ports
1 1

Cisco

Cisco N3K-C3016-FD-L3 | Nexus 3000 16-Port 40G QSFP+ Switch, DC, Layer 3

N3K-C3016-FD-L3

POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Cisco Nexus 3016 is a high-performance data center switch delivering wire-rate Layer 2 and Layer 3 switching with ultra-low latency. Designed for top-of-rack and spine-and-leaf architectures, it features 16 QSFP+ ports supporting native 40GbE or breakout to 64x10GbE. This DC-powered model includes forward airflow cooling and comes bundled with Base and LAN Enterprise licenses for advanced routing protocols including OSPF, BGP, EIGRP, VRF, and multicast.

Features

Wire-rate Layer 2 and Layer 3 switching across all ports
- Ultra-low latency architecture optimized for data center fabrics
- Advanced Layer 3 routing protocols: OSPF, BGP, EIGRP, IS-IS
- IP multicast support with PIM and IGMP
- Virtual Routing and Forwarding (VRF) for network segmentation
- Equal-Cost Multi-Path (ECMP) routing for load balancing
- Comprehensive Quality of Service (QoS) with traffic classification and queuing
- Access Control Lists (ACLs) for security and traffic filtering
- Role-Based Access Control (RBAC) for administrative security
- Port security and MAC address-based authentication
- Cisco Data Center Network Manager (DCNM) support
- Cisco NX-OS operating system with modular architecture
- Hot-swappable power supply and fan tray for redundancy
- Support for Cisco Nexus Data Broker for traffic monitoring
- Energy-efficient design optimized for data center deployments

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

16x QSFP+ ports supporting native 40GbE or 4x10GbE breakout mode per port
- Maximum configuration: 16x 40GbE or 64x 10GbE
- Switching capacity: 1.2 Tbps
- Forwarding rate: 950 million packets per second (mpps)
- Form factor: 1RU rackmount
- Airflow: Forward airflow (port-side exhaust)
- Power supply: DC power supply
- Memory: 8 GB DRAM
- Flash storage: 2 GB
- Management: 1x 10/100/1000 Ethernet management port, console port
- Jumbo frame support: MTU up to 9,216 bytes
- Operating system: Cisco NX-OS
- Licenses included: Base license (N3K-BAS1K9) and LAN Enterprise license (N3K-LAN1K9)
- Management protocols: CLI, SNMP v1/v2/v3, NETCONF, XML API, Cisco DCNM support

FAQs

Q: Can the QSFP+ ports be used for 10GbE connectivity?
A: Yes, each QSFP+ port can operate in native 40GbE mode or be broken out into 4x 10GbE ports using QSFP-to-SFP+ breakout cables or splitters, allowing up to 64x 10GbE ports total.

Q: What Layer 3 features are included with the LAN Enterprise license?
A: The bundled LAN Enterprise license enables full Layer 3 routing including OSPF, BGP, EIGRP, IS-IS, static routing, multicast routing (PIM, IGMP), VRF-Lite, policy-based routing (PBR), and ECMP for load balancing across multiple paths.

Q: What is the difference between forward and reverse airflow models?
A: This FD model features forward airflow with port-side exhaust, designed for data centers with front-to-back cooling where cold air enters the front and hot air exhausts from the rear. The alternative reverse airflow models support back-to-front cooling architectures.

Q: Is this switch suitable for low-latency applications?
A: Yes, the Nexus 3016 is designed for ultra-low latency applications with sub-microsecond latency, making it ideal for high-frequency trading, real-time analytics, storage networking, and other latency-sensitive workloads.

Q: What cabling options are supported?
A: The switch supports both copper and fiber cabling including QSFP+ Direct Attach Copper (DAC) Twinax cables for short distances, QSFP+ optical transceivers for longer reaches, and QSFP-to-SFP+ breakout cables for 10GbE connectivity.
