• Cisco Catalyst 9300 switch with 16x QSFP+ 40GbE ports
1 1

Cisco

Cisco N3K-C3016-BD-L3 | Nexus 3000 16-Port 40G QSFP+ Switch, DC, Layer 3

N3K-C3016-BD-L3

POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Cisco Nexus 3016 is a high-performance 1RU data center switch delivering wire-rate Layer 2 and Layer 3 switching at 40 Gigabit Ethernet. With 16 QSFP+ ports supporting native 40GbE or 4x10GbE breakout mode, it provides ultra-low latency and up to 1.28 Tbps switching capacity. This DC-powered model features port-side intake (reversed) airflow and includes Base and LAN Enterprise licenses for full routing capabilities.

Features

Wire-rate Layer 2 and Layer 3 switching on all ports with ultra-low latency
- Full Layer 3 routing protocol suite: BGP, OSPF, EIGRP, RIPv2, PIM-SM, SSM, MSDP
- Virtual PortChannel (vPC) for Layer 2 multipathing and redundancy
- 64-way Equal-Cost Multipath (ECMP) routing for scalable Layer 3 designs
- Cisco Nexus Data Broker support for network tap and SPAN aggregation
- Power On Auto Provisioning (POAP) for zero-touch deployment
- Advanced buffer monitoring for real-time traffic analysis
- EtherAnalyzer built-in packet analyzer based on Wireshark
- Precision Time Protocol (IEEE 1588) for clock synchronization
- Jumbo frame support up to 9216 bytes (MTU)
- Comprehensive security with ACLs (2000 ingress, 1000 egress entries)
- Cisco DCNM management support
- Redundant fans and dual power supply capability for high availability

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

16x 40 Gigabit Ethernet QSFP+ ports (each port supports 4x 10GbE breakout mode)
- Switching capacity: 1.28 Tbps
- Forwarding rate: 960 million packets per second (mpps)
- Form factor: 1 rack unit (1RU)
- Power supply: DC power with redundant PSU support (350W per PSU)
- Airflow: Port-side intake (reversed airflow)
- Management: 2x 100/1000 Mbps management ports, RS-232 console, USB
- Layer 3 license: Base + LAN Enterprise licenses included
- Memory: 4 GB RAM, 2 GB flash
- MAC address table: 128,000 entries
- Operating temperature: 0°C to 40°C (32°F to 104°F)
- Operating system: Cisco NX-OS

FAQs

Q: What license bundles are included with the N3K-C3016-BD-L3?
A: This SKU includes both the Base license (N3K-BAS1K9) and LAN Enterprise license (N3K-LAN1K9), enabling full Layer 3 unicast and multicast routing protocols including BGP, OSPF, EIGRP, RIPv2, and PIM out of the box.

Q: Can the QSFP+ ports be used for 10 Gigabit Ethernet connections?
A: Yes, each QSFP+ port can operate in either native 40 Gigabit Ethernet mode or 4x 10 Gigabit Ethernet mode using QSFP-to-SFP+ breakout cables, supporting both fiber and copper cabling solutions.

Q: What airflow direction does this model support?
A: The N3K-C3016-BD-L3 features port-side intake (reversed) airflow, meaning air is drawn in from the port side and exhausted from the fan side. This is important for data center hot aisle/cold aisle configurations.

Q: What is the typical use case for the Nexus 3016?
A: The Nexus 3016 is designed for high-performance, ultra-low-latency data center applications including financial trading platforms, top-of-rack (ToR) deployments, and high-density 40GbE or 10GbE aggregation with Layer 3 capabilities.

Q: Does this switch support redundant power supplies?
A: Yes, the Nexus 3016 supports dual redundant DC power supplies for enhanced reliability, though it can operate with a single power supply. Each DC PSU is rated at 350W.
