Cisco C1126-8PLTEP | ISR 1100 8-Port PoE+ Router, ADSL2/VDSL2+, LTE
SKU:C1126-8PLTEP
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Cisco ISR 1100 C1126-8PLTEP is a compact branch router for small and medium remote sites that need xDSL or fibre/Ethernet WAN links with cellular as backup or primary. It runs Cisco IOS XE in autonomous mode or as a Cisco SD-WAN edge, and the PoE+ capable LAN suits sites that power phones and access points from the router.
This SKU combines eight Gigabit Ethernet LAN ports with PoE/PoE+, one combo copper/SFP GE WAN port and an integrated ADSL2/VDSL2+ port supporting Annex B/J. A pluggable LTE module slot with GPS and SMS support provides cellular connectivity. It has 4 GB DRAM and 4 GB flash, while the C1126X variant steps up to 8 GB of each. In autonomous mode it delivers up to 1600 Mbps IPv4 forwarding and up to 600 Mbps IPsec throughput at 512B, and up to 700 Mbps SD-WAN IPsec throughput.
PoE and PoE+ on the 8-port models require the 150 W power supply, with PoE output at -53.5 VDC. This SKU is among the ISRs certified with the CAT 18 cellular pluggable P-LTEAP18-GL, and other pluggable cellular options include CAT4, CAT6, CAT7, 5G NSA and 5G SA modules.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Pluggable cellular slot supporting LTE CAT4, CAT6, CAT7 and CAT18 modules, plus 5G NSA and 5G SA options
- Integrated ADSL2/VDSL2+ with VDSL2 vectoring and dying gasp
- Combo GE copper/SFP WAN port for fibre or copper uplinks
- Optional PoE/PoE+ on the eight GE LAN ports
- Runs Cisco IOS XE in autonomous mode or Cisco SD-WAN mode
- Maximum encrypted throughput of 650 Mbps (single tunnel, IMIX)
- Larger-memory C1126X variant available for app hosting and SD-WAN advanced security
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- LAN ports: 8 x Gigabit Ethernet copper
- WAN ports: 1 x GE combo copper/SFP and 1 x ADSL2/VDSL2+ (Annex B/J)
- Cellular: pluggable LTE module slot with GPS and SMS support
- PoE: PoE/PoE+ on LAN ports (up to 4 PoE or 2 PoE+ on 8-port models) with 150 W power supply
- Memory: 4 GB DRAM and 4 GB flash (C1126X variant: 8 GB and 8 GB)
- Console: 1 x Micro-USB console port
- USB: 1 x USB 3.0 Type A port
- Minimum software: Cisco IOS XE 16.11.1; IOS XE SD-WAN 17.2.1
- Autonomous IPv4 forwarding throughput (512B): up to 1600 Mbps
- Autonomous IPsec throughput (512B): up to 600 Mbps
- SD-WAN IPsec throughput (512B): up to 700 Mbps
- SD-WAN profile throughput (IPsec, QoS, DPI, Flexible NetFlow, 512B): up to 250 Mbps
- SD-WAN overlay tunnels: 200
- IPsec SVTI tunnels: 100
- IPv4 routes: 280K
- IPv6 routes: 260K
- NAT sessions: 100K
- VRFs: 1K
- Maximum power consumption: 24.6 W excluding external power supply loss
- External power supply: 100-240 VAC, 50-60 Hz input, 12 VDC output, 66 W maximum
- Dimensions (H x W x D): 1.65 x 12.70 x 8.90 in.
- Weight: 4.53 lb (2.05 kg)
- Operating temperature: 0 to 40 C at sea level
- Operating humidity: 10% to 85% relative humidity, non-condensing
FAQs
Q: What power supply is needed for PoE and PoE+?
A: The 150 W power supply is required for PoE and PoE+ on the 8-port models, with PoE output at -53.5 VDC. The standard external adapter is rated 12 VDC at 66 W.
Q: Which cellular modules does it work with?
A: This SKU is certified with the CAT 18 pluggable P-LTEAP18-GL. Other pluggable options include CAT4, CAT6, CAT7, 5G NSA and 5G SA modules.
Q: How does it differ from the C1126X-8PLTEP?
A: The C1126-8PLTEP has 4 GB DRAM and 4 GB flash. The C1126X variant has 8 GB of each, suited to app hosting and SD-WAN advanced security.
Q: Can it be used as an SD-WAN edge?
A: Yes. It supports Cisco IOS XE SD-WAN from release 17.2.1 and up to 200 SD-WAN overlay tunnels.
Q: What WAN connections does it offer?
A: It has one GE combo copper/SFP WAN port, one ADSL2/VDSL2+ port supporting Annex B/J, and a pluggable cellular slot for LTE.
