Cisco

Cisco C1112-8PWE | ISR 1100 Router, 8-Port PoE+, G.fast Annex B, Wi-Fi 5

SKU:C1112-8PWE

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco ISR 1100 C1112-8PWE is a compact, fanless branch router that combines routing, an 8-port Gigabit Ethernet switch and an embedded 802.11ac Wi-Fi access point in a single device. It suits small branch offices, SOHO sites, retail stores, clinics and remote offices that need secure connectivity over a DSL service, running either traditional Cisco IOS XE or controller-managed IOS XE SD-WAN.

The WAN side pairs one Gigabit Ethernet copper/SFP combo port with an integrated DSL port supporting G.fast, VDSL2 and ADSL2+ on Annex B. The LAN side provides 8 Gigabit Ethernet ports. The embedded Wi-Fi is 802.11ac Wave 2, 2x2:2 MU-MIMO with rates up to 867 Mbps, in Wi-Fi domain E. Autonomous mode delivers up to 1800 Mbps IPv4 forwarding and up to 600 Mbps IPsec throughput at 512B, while SD-WAN mode supports up to 650 Mbps IPsec and 200 overlay tunnels. Memory is 4 GB DRAM and 4 GB flash. IP Base is the default technology package, with optional Application Experience, Unified Communications and Security packages.

The combo WAN port accepts SFPs such as GLC-SX-MM, GLC-LH-SM, GLC-T and GLC-TE. Optional PoE and PoE+ on the LAN ports is provided through the ISR-1100-POE4 with a 150W power supply, supporting 4 PoE or 2 PoE+ ports.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Router, 8-port switch and Wi-Fi access point combined in one compact fanless device
- Runs traditional Cisco IOS XE or controller-managed IOS XE SD-WAN
- Management through WebUI, Cisco DNA Center or Catalyst SD-WAN Manager
- On-box security including application-aware firewall, IPS/IDS, Advanced Malware Protection and URL filtering
- Cisco Umbrella SIG integration for cloud-delivered security
- Voice support with CUBE and SRST using the Unified Communications licence
- Integrated DSL WAN for copper broadband termination
- Pay-as-you-grow IPsec performance licensing

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Product family: Cisco ISR 1100 (C111x)
- LAN ports: 8 x Gigabit Ethernet (copper)
- WAN: 1 x Gigabit Ethernet copper/SFP combo port plus 1 x integrated DSL port
- DSL standards: G.fast (up to 106 MHz) Annex A/B/M, compatible with ADSL2/2+ and VDSL2
- VDSL2 profiles: 8a, 8b, 8c, 8d, 12a, 12b, 17a, 35b
- G.fast profiles: 106a, 106b
- Wi-Fi: embedded 802.11ac Wave 2, 2x2:2 MU-MIMO, up to 867 Mbps
- Wi-Fi domain: E
- Memory: 4 GB DRAM, 4 GB flash
- USB: 1 x Type A USB 3.0
- Console: Micro-USB/RJ-45
- IPv4 forwarding (autonomous, 512B): up to 1800 Mbps
- IPsec throughput (autonomous, 512B): up to 600 Mbps
- IPsec throughput (SD-WAN, 512B): up to 650 Mbps
- SD-WAN overlay tunnels: 200
- IPv4 routes: 280K
- IPv6 routes: 260K
- NAT sessions: 100K
- VRFs: 1K
- PoE: 4 PoE or 2 PoE+ ports with optional ISR-1100-POE4 and 150W power supply
- Power input: 100-240 VAC, 50-60 Hz, 12 VDC output
- Maximum power consumption: 38.2 W
- Dimensions (H x W x D): 1.75 x 12.70 x 9.015 in
- Weight: 2.16 kg (4.76 lb)
- Operating temperature: 0 to 40 C
- Minimum software: Cisco IOS XE 16.8.1

FAQs

Q: Does the C1112-8PWE need a licence?
A: IP Base is the default technology package. Optional packages include Application Experience, Unified Communications and Security, plus VPERF and HSEC IPsec performance upgrades. SD-WAN deployments use Cisco DNA subscriptions through a Smart Account.

Q: How is PoE provided on this router?
A: PoE and PoE+ on the LAN ports requires the optional ISR-1100-POE4 with a 150W power supply, which supports 4 PoE or 2 PoE+ ports. The standard external supply is a 12 VDC adapter rated at up to 66 W.

Q: Which SFPs work in the combo WAN port?
A: Supported SFPs include GLC-SX-MM, GLC-LH-SM, GLC-EX-SMD, GLC-ZX-SM, GLC-T and GLC-TE, along with 100BASE-FX/LX/BX, BX10/BX40/BX80, CWDM and DWDM SFPs.

Q: Which DSL standards does the integrated WAN port support?
A: It supports G.fast on Annex B, and is compatible with VDSL2 and ADSL2/2+. It handles VDSL2 profiles up to 35b and G.fast profiles 106a and 106b.

Q: Can this router run SD-WAN?
A: Yes. It supports Cisco IOS XE SD-WAN mode with up to 650 Mbps IPsec throughput and 200 overlay tunnels, as well as traditional autonomous IOS XE operation.
