Cisco 8102-64H-O | 8100 64-Port 100G QSFP28 Switch, SONiC, 2RU
SKU:8102-64H-O
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Cisco 8100 Series 8102-64H-O is a fixed 2RU data centre switch built on Cisco Silicon One. It runs the open-source SONiC network operating system and is aimed at hyperscale, cloud, HPC and AI/ML back-end networks that need dense 100G switching.
The chassis provides 64 x 100G QSFP28 ports with 6.4 Tbps of bandwidth. Ports support flexible rate configuration and breakout, including 4x 25G and 4x 10G modes, and the 8100 Series accepts QSFP+, QSFP28, QSFP56-DD, QSFP-DD800 and OSFP800 optics. An Intel 4-core 2.4-GHz CPU with 16 GB of DRAM handles the control plane. Typical system power at full 6.4 Tbps is 256 W, with two power supplies and three fans in an N+1 redundant design.
This is the Open Software (SONiC) variant without HBM. Management and timing connectivity includes RS-232 console, 1G management, a 10G control plane expansion port, USB 2.0 and 1588 timing interfaces.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Built on Cisco Silicon One ASIC for low power draw and a compact footprint
- Runs SONiC, the programmable, cloud-native open-source network operating system
- Flexible port rate configuration with breakout support
- Accepts a range of pluggable optics including QSFP+ and QSFP28
- N+1 redundant fan trays and redundant AC or DC power supplies
- Suited to AI/ML, HPC, cloud and hyperscale data centre networks
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Ports: 64 x 100GbE QSFP28
- Bandwidth: 6.4 Tbps
- Form factor: 2RU fixed chassis
- Software: Open Software (SONiC), without HBM
- CPU and memory: Intel 4-core 2.4-GHz CPU with 16 GB DRAM
- Port rates: 800G (8x 100G, 2x 400G), 400G, 100G, 40G, 25G, 10G
- Breakout support: 2x 400G, 8x 100G, 4x 100G, 2x 100G, 4x 25G, 4x 10G
- Supported optics: QSFP+, QSFP28, QSFP56-DD, QSFP-DD800, OSFP800
- Management interfaces: RS-232 console, 10G control plane expansion, 1G management, 1x USB 2.0
- Timing interfaces: GBP (ToD, 10 MHz, 1 PPS), 1588, BITs (sync)
- Typical system power at 6.4 Tbps: 256 W
- Power supplies and fans: 2 power supplies, 3 fans
- Redundancy: N+1 fan trays, N+1 AC or DC power supplies
- Dimensions (H x W x D): 8.77 x 43.9 x 51.1 cm
- Weight: 16 kg
- Operating temperature: 0 to 40 C
- Nonoperating temperature: -40 to 70 C
- Humidity: 5% to 95% non-condensing
- Altitude: 0 to 3000 m
- Safety: AS/NZS 62368.1, EN/IEC 62368-1, ANSI/UL 62368-1
- RoHS: RoHS 6 compliant with exceptions for leaded BGA balls and lead press-fit connectors
FAQs
Q: Does the 8102-64H-O need a software licence?
A: It ships with Open Software based on SONiC, an open-source network operating system. No additional licence or subscription is specified for this variant.
Q: What optics does it support?
A: The 64 ports are native QSFP28 for 100G. The 8100 Series also lists support for QSFP+, QSFP56-DD, QSFP-DD800 and OSFP800 optics, and breakout modes such as 4x 25G and 4x 10G are available.
Q: How is it powered?
A: It has two power supplies with N+1 redundant AC or DC options. Typical system power at the full 6.4 Tbps is 256 W.
Q: How does it differ from other Cisco 8100 models?
A: This SKU is the 64 x 100G QSFP28, 2RU variant with Open Software (SONiC) and without HBM. Other 8100 models differ in port count and software option.
Q: What network operating system does it run?
A: It runs SONiC, the open-source network operating system, rather than a closed Cisco operating system.
