Cisco 8102-28FH-DPU-O-MS | 8100 28x 400G QSFP-DD DPU Smart Switch, SONiC, 2RU
SKU:8102-28FH-DPU-O-MS
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Cisco 8100 28x 400G QSFP-DD DPU Smart Switch is a 2RU fixed data-centre switch from the Cisco 8100 Series, built on Cisco Silicon One. It suits Top-of-Rack and IP fabric leaf or spine roles, hyperscaler data centres, AI/ML front-end and back-end networks, and DPU-enabled smart switch deployments.
It provides 28 x 400G QSFP-DD ports (11.2 Tbps) plus 8 DPUs (1.6 Tbps) through 4 DPU card slots, for 12.8 Tbps of switching bandwidth. An Intel 16-core 2.5-GHz CPU handles control-plane duties. Power is supplied by 2 power supplies in a 1+1 redundant arrangement, with 4 fans for 3+1 redundant cooling, and typical power draw is 1210 W. This SKU runs open software (SONiC) and is the without-HBM variant, differentiated from other 8100 Series models by its DPU-enabled design.
The 8100 Series supports QSFP+, QSFP28, QSFP56-DD, QSFP-DD800 and OSFP800 optics form factors, with flexible port rates from 10G through 800G and breakout options including 2x 400G, 8x 100G and 4x 25G.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Built on Cisco Silicon One ASICs with high power efficiency and no HBM required
- Runs SONiC, the open-source network operating system, for integration into hyperscaler data centres
- Supports traditional data-centre deployments alongside open-software designs
- DPU-enabled design with 4 DPU card slots for smart switch use cases
- Positioned for high-density data-centre fabrics, including AI/ML networks
- Redundant hot-swappable power supplies and fan trays
- Flexible breakout options from 400G down to 10G
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Ports: 28x 400G QSFP-DD (11.2 Tbps)
- DPUs: 8x DPUs (1.6 Tbps) via 4 DPU card slots
- Switching bandwidth: 12.8 Tbps
- Form factor: 2RU fixed chassis
- CPU: Intel 16-core 2.5-GHz
- Management and console: RS-232 console, 1G management, 1x USB 2.0
- Power supplies: 2 (1+1 redundancy)
- Cooling: 4 fans (3+1 redundant cooling)
- Typical power: 1210 W
- Dimensions (H x W x D): 3.43 x 17.3 x 24.2 in. (8.76 x 43.95 x 67.4 cm)
- Weight: approx. 49 lb (22.2 kg) with power supplies and fans, approx. 40 lb (18.1 kg) without
- Operating temperature: 0 to 40 C (32 to 104 F)
- Nonoperating temperature: -40 to 70 C (-40 to 158 F)
- Humidity: 5% to 95% (noncondensing)
- Altitude: 0 to 3000 m (0 to 9842 ft)
- Flexible port rates: 800G, 400G, 100G, 40G, 25G, 10G
- Breakout support: 2x 400G, 8x 100G, 4x 100G, 2x 100G, 4x 25G, 4x 10G
- Supported optics: QSFP+, QSFP28, QSFP56-DD, QSFP-DD800, OSFP800
- Safety: AS/NZS 62368.1, UL/EN/IEC 62368-1, UL 60950-1, GB 4943-1
- RoHS: RoHS 6 compliant
FAQs
Q: Which operating system does this switch run?
A: It ships with open software based on SONiC, the open-source network operating system. This is the open software without HBM variant of the Cisco 8100 Series.
Q: How do the DPUs work in this switch?
A: The chassis has 4 DPU card slots supporting 8 DPUs in total (1.6 Tbps), each DPU complex having 400G of data bandwidth to the switch ASIC. This enables smart switch deployments.
Q: What optics does it support?
A: The 8100 Series supports QSFP+, QSFP28, QSFP56-DD, QSFP-DD800 and OSFP800 form factors. Breakout options include 2x 400G, 8x 100G, 4x 100G, 2x 100G, 4x 25G and 4x 10G.
Q: Is the power and cooling redundant?
A: Yes. It uses 2 power supplies in a 1+1 redundant arrangement and 4 fans for 3+1 redundant cooling. Typical power consumption is 1210 W.
Q: What sort of network roles is it designed for?
A: It is aimed at data-centre Top-of-Rack and IP fabric leaf or spine roles, hyperscaler environments, AI/ML front-end and back-end networks, and DPU-enabled smart switch deployments.
