Aruba R0P12A | SN6620C 48/24-Port 32G FC SAN Switch, Dual PSU

SKU:R0P12A

Request Quote

Sale Sold out

Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The SN6620C is a 1U 32 Gbps Fibre Channel SAN switch from the HPE C-series family, built for connecting servers to all-flash storage arrays. It suits dedicated standalone FC SANs, server-rack-to-SAN-core connectivity and FC-NVMe workloads, and can help consolidate separate SAN fabrics in small, midsize and large enterprises.

This 48/24-port model ships with 24 ports enabled and grows to 48 ports through 8-port upgrade licences. Every port runs at 32 Gbps with aggregate bandwidth of up to 1536 Gbps, and it also works with 16 and 8 Gbps optics. AES 128-bit encryption is supported, and the dual power supply configuration provides redundancy alongside optional redundant fans.

It runs NX-OS 8.3(1) or later, with Cisco DCNM Essentials Edition management software included. Optional licences cover the SN6000C Enterprise Package, the DCNM licence, the 8-port upgrade licence and SAN Insights for I/O visibility.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Consistent low-latency 32 Gbps performance on every FC port
- FC-NVMe ready, with enhanced buffer-to-buffer credits and FC link encryption
- Entry model scales from 24 to 48 ports in 8-port increments
- Same 32 Gbps ASIC as the SN8500C Fibre Channel Director
- ISL and HBA diagnostics, read diagnostic parameter, link cable beacon and FEC with HBA ports
- Slow-drain detection and isolation, VSAN, hardware ACLs and smart zoning
- REST and NX-API programmability
- Cisco DCNM Essentials Edition management software included

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Port speed: 32 Gbps Fibre Channel
- Port configuration: 48/24, 24 ports active, upgradable to 48 in 8-port steps
- Aggregate switch bandwidth: up to 1536 Gbps
- Optics supported: 32, 16 and 8 Gbps Fibre Channel
- Encryption: AES 128-bit
- Protocol: Fibre Channel
- Power: dual power supplies
- Form factor: 1U
- Dimensions (H x W x D): 4.37 x 43.9 x 56.6 cm
- Weight: 7.57 kg
- Required software: NX-OS 8.3(1) or later, DCNM 11.0(1) or later

FAQs

Q: How many ports are active on this switch and how do I add more?
A: It ships with 24 ports enabled. Additional ports are unlocked in 8-port steps with the SN6620C 8-port Upgrade licence, up to a total of 48 ports.

Q: Does it need a licence to run?
A: The switch runs NX-OS 8.3(1) or later and includes Cisco DCNM Essentials Edition. The SN6000C Enterprise Package, DCNM licence, 8-port Upgrade licence and SAN Insights are optional licences sold separately.

Q: Which Fibre Channel optics does it work with?
A: It supports 32, 16 and 8 Gbps Fibre Channel optics, so it can connect to existing 16G or 8G devices while running 32G where supported.

Q: Is it suitable for FC-NVMe and all-flash storage?
A: Yes. It is FC-NVMe ready and designed to connect servers to all-flash storage with consistent 32 Gbps performance on every port.

Q: What management software versions are required?
A: It requires NX-OS 8.3(1) or later and DCNM 11.0(1) or later.
