Aruba JL707C | CX 8360 48-Port 10G-T Switch, 4x 100G, Back-to-Front
SKU:JL707C
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The CX 8360-48XT4C v2 is a 1U fixed-configuration Layer 3 switch running AOS-CX, built for campus core and aggregation roles and for top-of-rack or end-of-row use in virtualised data-centre environments. It suits 10GBASE-T server access with 100G uplinks, and EVPN-VXLAN fabrics.
The front panel carries 48 Smart Rate 100M/1G/10GBASE-T ports (1/2.5/5/10G) and 4 x 40/100G QSFP+/QSFP28 uplink ports. The QSFP28 ports run at 100G or 40G only, with no breakout or split mode. This SKU is the back-to-front (power-to-port) airflow version with 3 hot-swappable fans and 2 hot-swappable 550W AC power supplies. The switch has 16GB RAM, 32GB flash and a 32MB packet buffer, with maximum power consumption of 500W and 120W at idle.
AOS-CX is included at no cost, covering Network Analytics Engine, Dynamic Segmentation, VSX high availability, Layer 2/3 routing and QoS, with no separate licence needed to operate. It supports Aruba transceivers from 1G SFP through 10G SFP+, 25G SFP28 and 100G QSFP28, plus DAC and optics options. Mounting options include 2-post and 4-post rack kits.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- AOS-CX operating system with built-in REST APIs and Python scripting for automation
- Network Analytics Engine (NAE) for telemetry, monitoring and troubleshooting
- VSX high availability with dual independent control planes
- Dynamic VXLAN with BGP-EVPN, distributed anycast gateway and ARP/ND suppression
- Layer 2/3 feature set including BGP, OSPF, VRF and IPv6
- Redundant hot-swappable power supplies and fans
- Smart Rate multi-gigabit support on the 48 copper ports
- MACsec on 2 of the 40/100G ports
- Dynamic Segmentation, QoS, IP multicast and NetEdit support
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Ports: 48 x 100M/1GbE/10GBASE-T (Smart Rate 1/2.5/5/10G)
- Uplinks: 4 x 40GbE/100GbE QSFP+/QSFP28 (no breakout/split support)
- Switching capacity: 2.4 Tbps
- Airflow: Back-to-front (power-to-port)
- Power supplies: 2 x hot-swappable 550W AC (JL712A power-to-port)
- Fans: 3 x hot-swappable (JL715A power-to-port)
- Power consumption: 500W maximum, 120W idle
- AC input current: 7.1A at 100-127VAC, 3.4A at 200-240VAC
- CPU: 1.8 GHz 4-core 64-bit
- Memory: 16GB RAM, 32GB flash
- Packet buffer: 32MB
- MAC address table size: 212,992
- IPv4 unicast routes: 606,977
- IPv6 unicast routes: 630,784
- Maximum VLANs: 4,094
- Management: RJ-45 serial and USB-C console, RJ-45 Ethernet port, USB Type-A
- Dimensions (H x W x D): 44.0 x 442.5 x 406.4 mm (1U)
- Full configuration weight: 8.01 kg
- Operating temperature: 0 to 40 C
- Heat dissipation: 1,706 BTU/hr
- Mounting: 19-inch EIA rack, 2-post and 4-post options
FAQs
Q: Does this switch need a software licence?
A: No separate licence is needed to operate. AOS-CX is included with a perpetual set of native features, including NAE, Dynamic Segmentation, VSX, Layer 2/3 routing and QoS. The optional CX Advanced Feature Pack is enabled by an Aruba Central Advanced subscription.
Q: What airflow direction does the JL707C use?
A: It is the back-to-front (power-to-port) airflow version, with 3 fans and 2 AC power supplies fitted to match. Replacement spares must also be power-to-port, namely the JL715A fan and the JL712A power supply.
Q: Can the 100G QSFP28 ports be split into 4x 25G?
A: No. The QSFP28 ports on the 48XT4C do not support breakout or split mode. They run at 100G or 40G only.
Q: Does it provide PoE?
A: No. The 48 copper ports carry data only. Power comes from 2 hot-swappable 550W AC supplies for the switch itself.
Q: Which optics and cables does it work with?
A: It supports Aruba 1G SFP (SX/LX/LH/RJ45), 10G SFP+ (SR/LR), 25G SFP28 and 100G QSFP28 optics and DAC per the Aruba transceiver guide. 10G LRM and 7m 10G DAC are not supported.
Q: Which rack mount kits are available?
A: The switch fits a 19-inch EIA rack. Options include the JL602A 2-post kit and the J9583B 4-post kit, and the JL716A 4-post air duct is available separately.
