Arista DCS-7280CR3-32P4-R | 7280R3 32-Port 100G Switch, 4x 400G OSFP, Rear-to-Front

SKU:DCS-7280CR3-32P4-R

Stock Status: Enquire

Request Quote

Sale Sold out

Shipping calculated at checkout.

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Arista 7280R3 is a 1RU fixed data centre switch router built for large-scale Layer 2 and Layer 3 cloud networks, spine and leaf and EVPN-VXLAN overlay designs, internet peering, interconnect and carrier edge VPN services. It runs Arista EOS and is managed with CloudVision.

The front panel provides 32 x 100GbE QSFP100 ports and 4 x 400GbE OSFP ports, with 4.8 Tbps of throughput (9.6 Tbps full duplex) and 2 Bpps of packet forwarding. Latency starts from 3.8 us and an 8 GB packet buffer with Virtual Output Queues avoids head-of-line blocking. This SKU has rear-to-front airflow, 2 x hot-swap AC power supplies (PWR-1011, 1+1 redundant) and 8 GB of system memory. It is listed in EOS Feature License Group 3 and requires EOS 4.22.1 or later.

The 400G OSFP ports support 400G, 200G, 100G, 50G and 25G breakout cables and optics, including 400GBASE-DR4, XDR4, FR4, LR4 and ZR. The QSFP100 ports support 100G, 40G, 50G and 25G/10G breakout.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Wire-speed Layer 2 and Layer 3 forwarding
- 8 GB deep packet buffer with Virtual Output Queues per port to avoid head-of-line blocking
- Up to 384K MAC addresses and over 2M IPv4 unicast routes
- EVPN-VXLAN, EVPN-MPLS, MPLS (LDP, RSVP-TE, SR-TE, TI-LFA) and BGP FlowSpec
- IEEE 1588 PTP and SyncE precision timing
- Live software patching and Stateful Fault Repair
- CloudVision management, ZTP, LANZ microburst detection and accelerated sFlow
- EOS programmability with Linux shell access, eAPI, NETCONF/RESTCONF, gNMI and OpenConfig

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Ports: 32 x QSFP100, 4 x OSFP
- Maximum 400G ports: 4
- Maximum 100G ports: 48
- Maximum 50G ports: 96
- Maximum 40G ports (using QSFP+): 36
- Maximum 25/10G ports: 96
- Throughput (FDX): 4.8 (9.6) Tbps
- Packets per second: 2 Bpps
- Latency: from 3.8 us
- CPU: Quad-core x86
- System memory: 8 GB
- Packet buffer memory: 8 GB
- Flash storage: 8 GB
- SSD storage: 120 GB with 64 GB system
- Management ports: 1 x 100/1000
- Serial console: 1 x RS-232 (RJ-45)
- USB ports: 1
- Power supplies: 2 x hot-swap AC PWR-1011 (1+1 redundant)
- Fans: 3 x hot-swap FAN-7011H (N+1 redundant)
- Airflow direction: rear to front
- Typical/maximum power draw: 535 W / 851 W
- Rack units: 1 U
- Dimensions (W x H x D): 43.99 x 4.37 x 55.83 cm
- Weight: 12.27 kg
- Minimum EOS version: 4.22.1
- Operating temperature: 0 to 40 C

FAQs

Q: Does this switch need a software licence?
A: It runs Arista EOS and is listed in EOS Feature License Group 3. Optional licences such as LIC-FIX-3-E for Enhanced L3 features and LIC-FIX-3-FLX for FLX routing are available for advanced functions.

Q: What power does it use?
A: It has 2 x hot-swap AC power supplies (PWR-1011, 1+1 redundant) with 100-240V AC IEC C14 inputs. Typical draw is 535 W and maximum draw is 851 W.

Q: Which optics and cables work in the 400G OSFP ports?
A: The OSFP ports support 400GBASE-CR8, AOC, SR8, DR4, XDR4, FR4, 2FR4, LR4, PLR4 and ZR, plus 200G, 100G, 50G and 25G breakout cables.

Q: Which airflow direction does this SKU have?
A: This DCS-7280CR3-32P4-R has rear-to-front airflow. Check the airflow direction of your rack layout before ordering.

Q: What EOS version does it need?
A: The minimum supported release is EOS 4.22.1.
