Arista DCS-7280CR2K-30-F | 7280R2K 30-Port 100G QSFP28 Switch, Front-to-Rear, 2x AC

SKU:DCS-7280CR2K-30-F

Stock Status: Enquire

Request Quote

Sale Sold out

Shipping calculated at checkout.

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Arista 7280R2K is a 1RU fixed data centre switch router from the 7280R series, built for large-scale layer 2 and layer 3 cloud designs, overlay networks, internet peering, interconnect and inter-DC networking. Deep buffers and large routing tables make it suited to service provider and enterprise data centre environments.

This SKU provides 30x 100GbE QSFP100 ports, which also support 50G, 40G, 25G and 10G modes, giving up to 120 breakout 25G or 10G ports. It delivers 6 Tbps of full-duplex throughput, a 2.51 Bpps forwarding rate, a 12 GB packet buffer and latency from 3.8 us. As a 7280R2K model with AlgoMatch-2 and expanded route memory, it supports over 2M IPv4 routes. Airflow is front-to-rear, with two 1600W AC hot-swap power supplies in a 1+1 arrangement and five hot-swap fans. Typical power draw is 565 W, with a maximum of 750 W.

The QSFP100 ports accept 100GBASE-SR4, LR4, CWDM4, PSM4 and other 100G optics, AOC and CR4 cables, as well as 40G QSFP+ optics and DACs. The switch runs Arista EOS 4.20.3 or later, sits in EOS Feature License Group 3 and integrates with CloudVision.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Virtual Output Queues on every port to eliminate head-of-line blocking
- Wire-speed layer 2 and layer 3 forwarding
- QSFP100 ports support quad 10GbE and 25GbE breakout modes
- 768K MAC addresses and 768K IPv4/IPv6 host routes, with over 2M IPv4 routes on the 7280R2K
- AlgoMatch-2 for scalable ACL and forwarding lookups
- VXLAN, LANZ microburst detection, DANZ advanced mirroring and TAP aggregation
- Zero Touch Provisioning, Advanced Event Monitoring and Accelerated sFlow
- Single-binary Arista EOS with full Linux shell access and CloudVision integration

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Ports: 30 x QSFP100 (100GbE, also 50/40/25/10GbE modes)
- Max 100GbE ports: 30
- Max 50GbE ports: 60
- Max 40GbE ports: 30
- Max 25GbE ports: 120
- Max 10GbE ports: 120
- Throughput (full duplex): 6 Tbps
- Forwarding rate: 2.51 Bpps
- Latency: From 3.8 us
- Packet buffer memory: 12 GB
- System memory: 32 GB
- Flash storage: 4 GB
- CPU: Multi-core x86
- Management ports: 1 x 100/1000, 1 x RS-232 (RJ-45), 1 x USB
- Power supplies: 2 x 1600W AC hot-swap (1+1 redundant)
- Fans: 5 hot-swap (N+1 redundant), tray FAN-7001D-F
- Airflow: Front to rear
- Typical / maximum power draw: 565 W / 750 W
- Form factor: 1 RU
- Dimensions (W x H x D): 48.3 x 4.4 x 67 cm
- Weight: 15.5 kg
- Operating temperature: 0 to 40 C
- Minimum EOS: 4.20.3
- EOS feature licence group: Group 3

FAQs

Q: Which EOS licences apply to this switch?
A: It runs Arista EOS and sits in Feature License Group 3. Optional Group 3 licences such as LIC-FIX-3-E (enhanced L3 routing), LIC-FIX-3-V (VXLAN and VM Tracer), LIC-FIX-3-Z (monitoring and automation) and LIC-FIX-3-FLX-L (FLX-Lite routing, EVPN and MPLS) are available separately.

Q: What power supplies does it use?
A: It uses two 1600W AC hot-swap power supplies (PWR-1600AC) in a 1+1 redundant arrangement with 100-240V AC input. Typical draw is 565 W and maximum draw is 750 W.

Q: Which optics and cables work in the 100G ports?
A: The QSFP100 ports accept 100GBASE-SR4, XSR4, SWDM4, SRBD, LR4, CWDM4, FR, DR, PSM4 and ERL4 optics, plus AOC and CR4 cables. They also accept 40G QSFP+ optics and DACs, and 25G or 10G breakout cables.

Q: How does the 7280R2K differ from other 7280R2 models?
A: The 7280R2K variant uses AlgoMatch-2 with expanded route memory, supporting over 2M IPv4 routes. This SKU also has front-to-rear airflow and two AC power supplies.

Q: What is the minimum software version required?
A: The switch requires Arista EOS 4.20.3 or later.
