• Silver metallic arista dcs-7130lbr-48s6qd-r 48-port 10g switch with 2 fpgas and 6 qsfp-dd ports and ventilation grilles
1 1

Arista

Arista DCS-7130LBR-48S6QD-R | 7130LBR 48-Port 10G Switch, 2x FPGA, 6x QSFP-DD

DCS-7130LBR-48S6QD-R

POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Arista DCS-7130LBR-48S6QD-R is an advanced Layer 1 application switch designed for high-frequency trading, financial services, and data center environments requiring ultra-low latency and FPGA programmability. With 48x 10G SFP+ ports, 6x QSFP-DD uplinks supporting up to 96x 10G lanes via breakout, and dual VU9P-3 FPGAs, it delivers 2.4 Tbps throughput with sub-microsecond latency. The composable architecture with integrated Layer 1 crosspoint enables flexible port configuration for in-band switching or out-of-band telemetry, making it ideal for tap aggregation, real-time analytics, and custom FPGA applications.

Features

Dual Xilinx VU9P-3 FPGAs for custom application development and acceleration
- Layer 1 crosspoint architecture for flexible port mapping and signal routing
- Virtual Output Queue (VOQ) architecture eliminates head-of-line blocking
- Deep buffer design virtually eliminates packet loss in congested scenarios
- Advanced traffic scheduler with weighted fair queuing, fixed priority, and hybrid modes
- DANZ (Data ANalyZer) feature set for tap aggregation and network visibility
- Precision Time Protocol (PTP) IEEE 1588v2 with optional PPS inputs
- Ultra-low latency design optimized for high-frequency trading applications
- Arista EOS operating system with ZTP, CloudVision integration
- L2 features: VLANs, STP, MLAG, Link Aggregation
- L3 features: OSPF, BGP, static routing, multicast support
- FPGA Development Kit (FDK) with comprehensive API and sample code
- In-band and out-of-band port configuration via crosspoint
- System-wide hardware and software monitoring for reliability
- Hot-swappable redundant power supplies with rear-to-front cooling
- 1RU space-saving design with high port density

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

Port Configuration: 48x 10G SFP+ ports, 6x QSFP-DD ports (NRZ)
- QSFP-DD Breakout: Each QSFP-DD supports 2x 40GbE or 8x 10GbE, up to 96x 10G total lanes
- Switching Capacity: 2.4 Tbps throughput
- Layer 1 Latency: 6 microseconds
- FPGA: Dual Xilinx VU9P-3 FPGAs for custom application development
- Architecture: Layer 1 crosspoint for flexible port mapping and tap aggregation
- Layer 2/3 Features: L2/L3 forwarding with VOQ architecture, advanced routing capabilities
- Power Draw: 391W typical, 650W maximum
- Power Supplies: Dual redundant AC PSU (PWR-1511-AC or PWR-1512-AC supported)
- Airflow: Rear-to-front (R-Series)
- Form Factor: 1RU rack-mountable
- Management: EOS (Extensible Operating System), CLI, SNMP, ZTP
- Precision Timing: IEEE 1588v2 PTP support with optional PPS inputs
- Operating Temperature: 0°C to 40°C ambient

FAQs

Q: What applications is the DCS-7130LBR-48S6QD-R best suited for?
A: This switch is optimized for high-frequency trading, financial markets, data center tap aggregation, network monitoring with streaming telemetry, and custom FPGA-accelerated applications requiring ultra-low latency and high bandwidth. The dual VU9P-3 FPGAs enable development of custom network processing, packet filtering, timestamping, and real-time analytics applications.

Q: Can the QSFP-DD ports be broken out into multiple 10G connections?
A: Yes, each of the 6x QSFP-DD ports can be broken out to 2x 40GbE or 8x 10GbE interfaces using appropriate breakout cables. This allows the switch to support up to 96x 10G lanes in total, providing exceptional port density and flexibility for high-bandwidth connectivity.

Q: Does this switch require any special licensing for Layer 3 routing features?
A: The DCS-7130LBR-48S6QD-R supports L2/L3 forwarding and advanced routing features through Arista EOS. For full routing capabilities including EVPN, VXLAN, Segment Routing, and advanced MPLS, an FLX License for Arista Fixed switches Group 4 is available, supporting up to 2M routes and over 24K ACL entries.

Q: What is the Layer 1 crosspoint feature and how does it work?
A: The Layer 1 crosspoint is a composable architecture that allows any front-panel port to be flexibly mapped 1:1 or mirrored to any platform component including the integrated switch, FPGAs, or other ports. Ports can be configured as in-band for switching and routing, or out-of-band for telemetry and FPGA processing, enabling diverse deployment scenarios without hardware changes.

Q: Is FPGA development supported and what tools are available?
A: Yes, Arista provides an FPGA Development Kit (FDK) that includes API documentation, sample code, and IP cores to streamline custom application development for the dual VU9P-3 FPGAs. This enables network engineers and developers to create specialized packet processing, timestamping, filtering, and analytics functions tailored to specific business requirements.
