Arista DCS-7130-48LBAS-R | 7130 48-Port 10G SFP+ FPGA Switch, VU9P-3, Atomic Clock

SKU:DCS-7130-48LBAS-R

Stock Status: Enquire

Request Quote

Sale Sold out

Shipping calculated at checkout.

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Arista 7130 Series is a Layer 1+ FPGA-enabled switch built for ultra-low latency trading, exchange connectivity, market data fan-out and precision network monitoring. This 1U model combines a Xilinx Virtex UltraScale+ VU9P Speed Grade 3 FPGA with an onboard atomic clock, making it suited to colocation environments and teams developing custom FPGA applications.

It provides 48 SFP+ ports supporting 100M to 11.3Gbps, plus 2 RJ45 ports. Layer 1 forwarding latency is 5 ns, with MetaMux latency of 39 ns and MultiAccess latency of 55 ns. The FPGA has 32GB of DDR memory, and a quad-core x86 CPU with 8GB RAM and a 64GB onboard SSD runs the Linux-based platform. This SKU has rear-to-front airflow and two AC power supplies, with a maximum power draw of 430W.

The SFP+ ports accept 10GBASE-CR, SRL, SR, LRL, LR, ER and DWDM optics, along with 40GBASE-CR4 breakout cabling. FPGA applications are developed with the FDK and Vitis Dev Kit, and the switch also has PPS input and output for time synchronisation.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Layer 1+ forwarding with deterministic ultra-low latency and less than 100 ps jitter
- Signal regeneration and media conversion
- Port mirroring with the same latency for 1:N replication
- Dynamic patching and link management
- Layer 1+ packet statistics on every link
- Embedded influxdb database for telemetry
- Eye diagram, tcpdump diagnostics and full SFP+ diagnostics on every port
- Linux-based platform with industry-standard CLI and JSON RPC API
- Integrated FPGA available for Arista or third-party applications
- Hot-swappable redundant power supplies and fans

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Ports: 48 x SFP+ (100M-11.3Gbps), 2 x RJ45
- FPGA: Xilinx Virtex UltraScale+ VU9P Speed Grade 3
- FPGA memory: 32GB DDR
- Layer 1 latency: 5 ns
- MetaMux latency: 39 ns
- MultiAccess latency: 55 ns
- Clock: Atomic
- CPU: Quad-core x86
- System memory: 8GB RAM
- On-board SSD: 64GB
- Management ports: 2 x 100/1000
- USB ports: 1
- Serial console: 1 x RS-232 (RJ-45)
- PPS input: 1 x 5V TTL, 50 ohm
- PPS output: 1 x 5V TTL
- Internal 10G ports: 2
- Power supplies: 2 x hot-swap AC, 1+1 redundant
- Fan trays: 2 x hot-swap, 1+1 redundant
- Airflow: Rear-to-front
- Maximum power draw: 430W
- Form factor: 1U
- Dimensions (W x H x D): 44.8 x 4.3 x 37.9 cm
- Weight: 9 kg
- Operating temperature: 0 to 40 C
- Relative humidity: 10% to 85% non-condensing

FAQs

Q: What power configuration does this SKU use?
A: It is the 2xAC configuration, with dual hot-swap PWR-500 AC power supplies in a 1+1 redundant arrangement. Maximum power draw is 430W.

Q: What airflow direction does this model have?
A: This -R model has rear-to-front airflow. The matching spare fan module is FAN-7130-1U-R and the spare AC power supply is PWR-500AC-R.

Q: Which optics and cables work in the SFP+ ports?
A: The ports support 10GBASE-CR DAC (0.5 to 5m), SRL, SR, LRL, LR, ER and DWDM optics, plus 40GBASE-CR4 cabling.

Q: Can I run custom applications on the FPGA?
A: Yes. The integrated VU9P-3 FPGA supports Arista and third-party applications, developed using the FDK and Vitis Dev Kit.

Q: How does this model differ from other 7130 variants?
A: This SKU combines 48 SFP+ ports, the VU9P-3 FPGA, an atomic clock, rear-to-front airflow and two AC power supplies.
