Arista DCS-7130-48LBAS-F | 7130L 48-Port 10G SFP+ FPGA Switch, VU9P-3, Atomic Clock

SKU:DCS-7130-48LBAS-F

Stock Status: Enquire

Request Quote

Sale Sold out

Shipping calculated at checkout.

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Arista 7130LS Series 48LBAS is a 1U Layer 1+ FPGA switch built for latency-critical environments. It is aimed at trading firms, exchanges, colocation operators and monitoring teams who need deterministic nanosecond-level forwarding, tap aggregation and the ability to run custom FPGA applications on the switch itself.

The switch provides 48 SFP+ ports supporting 100M to 11.3Gbps, plus 2 RJ45 ports, around a Xilinx Virtex UltraScale+ VU9P Speed Grade 3 FPGA with 32GB DDR. An atomic clock is fitted, with PPS input and output ports for time synchronisation. Layer 1 latency is 5 ns, MetaMux is 39 ns and MultiAccess is 55 ns, with jitter under 100 ps. This SKU has front-to-rear airflow, two hot-swap AC power supplies (1+1) and dual hot-swap fan trays, with a maximum power draw of 430W.

Supported Arista applications on this model are MetaWatch, SwitchApp, FDK and VDK. The SFP+ ports accept 10GBASE-CR, SR, LR, ER and DWDM optics as well as 1000BASE-T modules.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Nanosecond-level deterministic Layer 1 forwarding, with the same latency for 1:N port mirroring
- Full signal recovery and regeneration with bit-for-bit forwarding for any protocol
- Media conversion, port mirroring, dynamic patching and ad-hoc tapping without rewiring
- Layer 1+ packet statistics, tcpdump, LLDP, eye diagram and full SFP+ diagnostics on every port
- Embedded InfluxDB database and streaming telemetry
- Linux-based platform with industry-standard CLI and JSON RPC API
- Built-in application framework for packaging and deploying FPGA applications
- Non-blocking design with redundant hot-swap power supplies and fan trays

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Ports: 48 x SFP+ (100M-11.3Gbps), 2 x RJ45
- FPGA: Xilinx Virtex UltraScale+ VU9P Speed Grade 3
- DRAM: 32GB DDR
- System memory: 8GB RAM
- On-board SSD: 64GB
- CPU: Quad-Core x86
- Clock: Atomic
- Layer 1 latency: 5 ns
- MetaMux latency: 39 ns
- MultiAccess latency: 55 ns
- Jitter: less than 100 ps
- Internal 10G ports: 2
- Management ports: 2 x 100/1000
- USB ports: 1
- PPS input: 1 (5V TTL, 50 ohm)
- PPS output: 1 (5V TTL)
- Serial console: 1 x RS-232 (RJ-45)
- Power supplies: 2 x hot-swap AC, 1+1 redundant
- Fan trays: 2 x hot-swap, 1+1 redundant, front-to-rear airflow
- Maximum power draw: 430W
- Rack units: 1U
- Dimensions (W x H x D): 44.8 x 4.3 x 37.9 cm
- Weight: 9 kg
- Operating temperature: 0 to 40 C
- Relative humidity: 10% to 85% non-condensing
- Maximum altitude: 2,000 m

FAQs

Q: Which Arista applications run on this model?
A: The 48LBAS supports MetaWatch, SwitchApp, FDK (FPGA Dev Kit) and VDK (Vitis Dev Kit). ExchangeApp and MetaProtect are not supported on LBS/LBAS models.

Q: What optics can I use in the SFP+ ports?
A: The ports support 10GBASE-CR (0.5-5m), SRL, SR, LRL, LR, ER and DWDM optics, plus 1000BASE-T and 40GBASE-CR4 breakout cabling. Speeds range from 100M to 11.3Gbps.

Q: What power supplies does this SKU use?
A: It uses two hot-swap PWR-500 AC supplies in a 1+1 redundant arrangement, rated 100-240V AC with a C13 inlet. Maximum system draw is 430W.

Q: What airflow direction does this SKU have?
A: This SKU is front-to-rear airflow. Spare parts are the FAN-7130-1U-F fan module and PWR-500AC-F power supply.

Q: What is the latency of this switch?
A: Layer 1 forwarding latency is 5 ns, MetaMux is 39 ns and MultiAccess is 55 ns, with jitter under 100 ps.
