Arista DCS-7130-16G3S-F | 7130 Connect 16-Port 10G Layer 1 Switch, 2x AC

SKU:DCS-7130-16G3S-F

Stock Status: Enquire

Request Quote

Sale Sold out

Shipping calculated at checkout.

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Arista 7130 Connect 16-port switch is a Layer 1+ device from the 7130S Connect Series, built for ultra-low-latency environments. It forwards data in 4 ns with full signal regeneration, and can act as a remotely configurable patch panel, tap, kill-switch or media converter. Typical uses include one-to-many data broadcast, ad-hoc tapping, link monitoring and latency-sensitive networks.

It provides 16 SFP+ ports supporting 100M, 1GbE and 10GbE, plus a single RJ45 port. Per-port throughput runs from 100M to 11.3Gbps non-blocking, with less than 100 ps jitter. This variant is a 1U chassis with front-to-rear airflow and two hot-swappable 1+1 redundant AC power supplies (PWR-500AC), with a maximum system draw of 190W. The two fan trays are also hot-swappable and redundant.

It accepts SFP and SFP+ optics and cables including 1000BASE-T, 1000BASE-SX and LX, and 10GBASE-CR DAC, SR, SRL, LR, LRL, ER and DWDM. Management is Linux-based on an x86-64 platform with an industry-standard CLI and JSON RPC API, plus Layer 1+ packet statistics, eye diagram monitoring and full SFP+ diagnostics on every port.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- 4 ns deterministic latency with less than 100 ps jitter
- Crosspoint switching for a remotely configurable patch panel, kill-switch and failed-link bypass
- Full signal recovery and regeneration with clock and data recovery on input and output
- Media conversion between different media types running at the same rate
- Protocol agnostic, bit-for-bit forwarding for any protocol
- Layer 1+ packet statistics, eye diagram monitoring and tcpdump diagnostics on every port
- Same latency for 1:N port mirroring
- Linux-based x86-64 management with industry-standard CLI, JSON RPC API and LLDP topology discovery

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Ports: 16 x SFP+ (100M/1GbE/10GbE), 1 x RJ45
- Throughput: 100M-11.3Gbps per port, non-blocking
- Latency: 4 ns
- Jitter: less than 100 ps
- CPU: Quad-Core x86
- System memory: 8 GB RAM
- On-board SSD: 64GB
- USB ports: 1
- Management ports: 2 x 100/1000
- Serial console: 1 x RS-232 (RJ-45)
- Power supplies: 2 x PWR-500AC, hot-swap, 1+1 redundant
- PSU input: 100-240V AC, 50/60Hz, IEC 320-C13
- Fan trays: 2 x FAN-7130-1U, hot-swap, 1+1 redundant
- Airflow: front-to-rear
- Rack units: 1U
- Dimensions (WxHxD): 44.8 x 4.3 x 37.9 cm
- Weight: 9kg
- Maximum power draw: 190W
- Operating temperature: 0 to 40 C
- Relative humidity: 10% to 85% non-condensing
- Maximum altitude: 2,000m

FAQs

Q: Does this switch need a software licence?
A: No licence requirement is specified for this SKU. It is a Layer 1+ switch with its Linux-based management software included.

Q: What power supplies does this model use?
A: It uses two hot-swappable PWR-500AC power supplies in a 1+1 redundant arrangement, accepting 100-240V AC at 50/60Hz through IEC 320-C13 connectors. Maximum system power draw is 190W.

Q: Which optics and cables work with the SFP+ ports?
A: The SFP+ ports support 1000BASE-T, 1000BASE-SX and LX, and 10GBASE-CR DAC (0.5-5m), SR, SRL, LR, LRL, ER and DWDM modules. 40GBASE-CR4 QSFP+/SFP+ cabling is also listed.

Q: What is the airflow direction on this SKU?
A: This variant is front-to-rear airflow. Spare fan trays are available as FAN-7130-1U-F and spare power supplies as PWR-500AC-F.

Q: What can the Layer 1+ function be used for?
A: It can be configured remotely as a patch panel, one-to-many broadcast point, ad-hoc tap, link monitor or media converter, all with 4 ns forwarding latency.
