• Gray metal arista dcs-7060px4-32-f 12.8tbps 1ru switch back side with multiple black ports and ventilation slots
1 1

Arista

Arista DCS-7060PX4-32-F | 7060X4 32-Port 400G OSFP Switch, 12.8Tbps, 1RU

DCS-7060PX4-32-F

POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Arista DCS-7060PX4-32-F is a high-performance 1RU data center switch delivering 32x 400GbE OSFP ports with a total throughput of 12.8Tbps. Designed for hyperscale cloud networks and AI/ML workloads, it supports flexible port speeds including 400GbE, 200GbE, and 100GbE with breakout capabilities up to 128 interfaces. Powered by Arista EOS, this switch features ultra-low latency as low as 700ns, advanced Layer 2/3 capabilities including VXLAN and EVPN, and front-to-rear airflow for hot aisle/cold aisle deployments.

Features

32x 400GbE OSFP ports supporting 400G/200G/100G/50G/40G speeds with flexible breakout
- 25.6Tbps full-duplex switching capacity with 8 Bpps forwarding rate
- Ultra-low latency of 700ns in cut-through mode for AI/ML and HPC workloads
- 64MB shared packet buffer for superior burst absorption
- Arista EOS operating system with advanced automation and telemetry
- Layer 2 switching with IEEE 802.1Q VLAN support (up to 4,000 VLANs)
- Spanning Tree Protocol (STP, RSTP, MSTP) for loop prevention
- Link Aggregation with IEEE 802.3ad LACP support
- Jumbo frame support up to 9,216 bytes
- Full IPv4 and IPv6 routing with OSPF, BGP, IS-IS, RIP, and static routing
- Equal-Cost Multi-Path (ECMP) routing supporting up to 128-way load balancing
- VXLAN and EVPN for network virtualization and multi-tenancy
- Multicast routing with PIM-SM, PIM-SSM, and IGMP
- VRF-lite for network segmentation and isolation
- Advanced QoS with congestion management, DCTCP, and ECN support
- Comprehensive security with ACLs, port security, Dynamic ARP Inspection, and DHCP snooping
- AAA integration with RADIUS and TACACS+ for centralized authentication
- Management via CLI, SNMP, REST API, sFlow, and CloudVision telemetry
- Hot-swappable redundant power supplies and fan modules for high availability
- Zero Touch Provisioning (ZTP) for automated deployment

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

Port Configuration: 32x 400GbE OSFP ports (supports 400GbE, 200GbE, 100GbE, 50GbE, 40GbE)
- Breakout Support: Up to 128x 100GbE interfaces via port breakout
- Management Ports: 1x Gigabit Ethernet RJ45, 1x RS-232 RJ45 console, 1x USB Type-A
- Switching Capacity: 25.6Tbps full-duplex
- Throughput: 12.8Tbps
- Forwarding Rate: 8 Bpps (billion packets per second)
- Latency: As low as 700ns in cut-through mode
- Packet Buffer: 64MB shared buffer
- MAC Address Table: Up to 72,000 MAC addresses
- Memory: 8GB system memory, 8GB flash
- Power Supply: Dual redundant 1600W AC power supplies (PWR-1611-AC-RED), hot-swappable
- Power Consumption: 342W typical (up to 450W under full load)
- Airflow: Front-to-rear (F designation)
- Fan Modules: 5x hot-swappable, redundant fans (FAN-7001DH-F)
- Dimensions (HxWxD): 1.7" x 17.3" x 26.4" (1RU)
- Weight: 21 lbs (9.5 kg) approximate
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Humidity: 5% to 95% non-condensing
- Certifications: UL, CSA, CE, RoHS, FCC Part 15 Class A
- Operating System: Arista EOS with CLI, SNMP, REST API, CloudVision support

FAQs

Q: What optics are compatible with the DCS-7060PX4-32-F?
A: The DCS-7060PX4-32-F uses OSFP form factor optics and supports industry-standard 400G, 200G, and 100G transceivers. Note that OSFP is not backward compatible with QSFP+ or QSFP28 modules. Arista provides a wide range of compatible optics and DAC/AOC cables for various distances and applications.

Q: Can this switch be used in both spine and leaf configurations?
A: Yes, the DCS-7060PX4-32-F is highly versatile and can be deployed as either a spine or leaf switch in modern data center architectures. Its high port density and 400G capability make it ideal for spine deployments, while its breakout support allows flexible leaf configurations with up to 128x 100GbE server connections.

Q: What is the difference between the DCS-7060PX4-32 and DCS-7060DX4-32?
A: The primary difference is the port type: the DCS-7060PX4-32 uses OSFP ports while the DCS-7060DX4-32 uses QSFP-DD ports. Both deliver 32x 400GbE ports in 1RU with 12.8Tbps throughput and identical features, allowing customers to choose based on their preferred optics ecosystem and cabling infrastructure.

Q: Does this switch require a software license to operate?
A: The DCS-7060PX4-32-F runs Arista EOS, which includes comprehensive Layer 2 and Layer 3 features out of the box. Arista's licensing model is subscription-based for CloudVision management and support services, but core switching functionality is available without additional licenses. Contact Arista or an authorized partner for specific licensing requirements.

Q: What redundancy features are included?
A: The switch includes dual redundant 1600W hot-swappable AC power supplies and five hot-swappable fan modules with N+1 redundancy. Arista EOS also supports Stateful Fault Repair, Smart System Upgrade for zero-downtime software updates, and MLAG for link-level redundancy in network designs.
