Arista DCS-7050SX3-48YC8-F | 7050X3 48-Port 25G SFP Switch, 8x 100G, Front-to-Rear, 2xAC

SKU:DCS-7050SX3-48YC8-F

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

Condition
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Arista 7050X3 series 7050SX3-48YC8 is a 1RU data centre leaf or spine switch built for dense 25G server and storage access with 100G uplinks. It suits cloud, virtualised and storage networks that need wire-speed forwarding without oversubscription, and it runs Arista EOS.

This model provides 48 SFP ports that run at 25G or a mix of 10G and 1G, plus 8 QSFP100 ports that support 100GbE or 40GbE. Overall throughput is 2 (4) Tbps with 1 Bpps packet forwarding and latency from 800 ns. A 32 MB dynamic shared packet buffer helps absorb bursts. This SKU has front-to-rear airflow and 2 hot-swappable AC power supplies in a 1+1 redundant arrangement, with a typical draw of 124W and a maximum of 301W.

Spare parts for this configuration include the FAN-7011M-F fan module and PWR-511-AC-RED/BLUE power supply. Minimum EOS is 4.21.6, and optional feature licences are available under the LIC-FIX-2 family.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Wire-speed Layer 2 and Layer 3 forwarding with latency from 800 ns
- Fully shared 32 MB packet buffer with dynamic allocation for burst absorption
- 1+1 redundant hot-swappable power supplies and hot-swappable fans
- Runs Arista EOS with VXLAN, VM Tracer, OpenFlow, DirectFlow and eAPI
- Provisioning and monitoring with CloudVision, Zero Touch Provisioning, LANZ microburst detection and sFlow
- High availability with live software patching, Smart System Upgrade, MLAG and 128-way ECMP
- Unified forwarding table with 288K MAC entries and 360K IPv4 routes

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Ports: 48x SFP25, 8x QSFP100
- Max 100GbE ports: 8
- Max 50GbE ports: 16
- Max 40GbE ports: 8
- Max 25GbE ports: 64
- Max 10GbE ports: 64
- Max 1GbE ports: 48
- Throughput: 2 (4) Tbps
- Packets per second: 1 Bpps
- Latency: 800 ns
- CPU: Quad-Core x86
- System memory: 8 GB
- Flash storage: 8 GB
- Packet buffer memory: 32 MB dynamic allocation
- Management ports: 1
- RS-232 serial ports: 1 (RJ-45)
- USB ports: 1
- Power supplies: 2 hot-swap AC, 1+1 redundant
- Hot-swappable fans: 2, 1+1 redundant
- Airflow: front-to-rear
- Typical/Max power: 124W / 301W
- Rack units: 1RU
- Dimensions (W x H x D): 44 x 4.4 x 46.8 cm
- Weight: 9.45 kg
- Operating temperature: 0 to 40 C

FAQs

Q: Which licences are available for this switch?
A: It runs Arista EOS. Optional feature licences from the LIC-FIX-2 family include Enhanced L3 (LIC-FIX-2-E), VMTracer and VXLAN (LIC-FIX-2-V), EOS extensions and security (LIC-FIX-2-V2), monitoring and automation (LIC-FIX-2-Z) and FLX-Lite routing (LIC-FIX-2-FLX-L).

Q: What power supplies does it use?
A: It uses two hot-swap AC supplies in a 1+1 redundant arrangement, part PWR-511-AC-RED/BLUE. Each accepts 100-240V AC at 50/60Hz and provides 500W output.

Q: Can the SFP ports run at speeds below 25G?
A: Yes. The 48 SFP ports can run at 25G or a mix of 10G and 1G. The 8 QSFP100 ports support 100GbE or 40GbE.

Q: What is the airflow direction, and which fan module does it need?
A: This SKU has front-to-rear airflow. The matching spare fan module is FAN-7011M-F.

Q: What is the minimum EOS version?
A: The minimum supported EOS release is 4.21.6.
