Arista DCS-7050SX3-48C8C-F | 7050X3 48-Port 10G SFP+ Switch, 8x 100G, Front-to-Rear
SKU:DCS-7050SX3-48C8C-F
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Arista 7050X3 series 7050SX3-48C8C is a 1RU data centre leaf switch built for 10G server and storage access with 100G uplinks to the spine. It suits top-of-rack deployments in data centres, as well as enterprise, carrier, cloud, virtualised and big-data environments, and runs Arista EOS.
It provides 48 SFP+ ports (10G/1G) and 8 QSFP100 ports that support 100G and 40G, with 50G, 25G and 10G available through breakout. Throughput is 1.28 (2.56) Tbps at 1 Bpps with 800 ns latency and a 32 MB dynamic packet buffer. This -F variant has front-to-rear airflow, two hot-swap 500W AC power supplies in a 1+1 redundant arrangement, two hot-swap fans, a quad-core x86 CPU, 16GB RAM and 32GB flash. Typical power draw is 105 W and the maximum is 259 W.
The SFP+ ports accept 10GBASE-CR, AOC, SR, LR, ER, ZR and DWDM optics as well as 10GBASE-T copper modules, while the QSFP100 ports take 100GBASE and 40GBASE optics, AOC and DAC cables and breakout cables. EOS 4.30.4 or later is required.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Wire-speed Layer 2 and Layer 3 forwarding with a Unified Forwarding Table for flexible MAC, route and host entry partitioning
- 288K MAC entries, 360K IPv4 routes (ALPM mode), 128-way ECMP and 64-way MLAG
- VXLAN routing, bridging and gateway, EVPN, VRF, BGP, OSPF, IS-IS and PIM
- LANZ microburst detection, sFlow, DMF, Zero Touch Provisioning, CloudVision, eAPI and OpenConfig
- IEEE 1588 PTP, Network Address Translation, Dynamic Load Balancing, PFC/DCBX and ECN
- Over 94% efficient power supplies with 1+1 hot-swap redundancy and tool-less rails
- Stateful Fault Repair, live software patching and full Linux shell access
- Hitless port speed changes from 10G to 100G
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Ports: 48x SFP+ (10G/1G), 8x QSFP100
- Uplink speeds: 100G/40G native, 50G/25G/10G via breakout
- Throughput: 1.28 (2.56) Tbps
- Packets per second: 1 Bpps
- Latency: 800 ns
- Packet buffer: 32 MB (dynamic buffer allocation)
- CPU: Quad-core x86
- System memory: 16 GB
- Flash storage: 32 GB
- Management ports: 1x 10/100/1000
- Serial port: 1x RS-232 (RJ-45)
- USB ports: 1
- Power supplies: 2x hot-swap 500W AC (1+1 redundant)
- Fans: 2x hot-swap (1+1 redundant)
- Airflow: Front to rear
- Typical / maximum power: 105 W / 259 W (excludes transceivers)
- Form factor: 1RU
- Dimensions (W x H x D): 44 x 4.4 x 46.8 cm
- Weight: 9.45 kg
- Operating temperature: 0 to 40 C
- Minimum EOS release: 4.30.4
FAQs
Q: Does this switch need a licence?
A: It runs Arista EOS, and the datasheet lists LIC-FIX-1 as the EOS feature licence group for the 7050SX3-48C8C. Optional add-on licences are available separately, including LIC-FIX-1-E for Enhanced L3, LIC-FIX-1-V for virtualisation and LIC-FIX-1-Z for monitoring and automation.
Q: What power supplies does this model use?
A: This front-to-rear airflow model uses two hot-swap 500W AC supplies in a 1+1 redundant arrangement, part number PWR-511-AC-RED. They accept 100-240V AC at 50/60Hz through an IEC 60320 C14 connector.
Q: Which optics and cables work with the ports?
A: The SFP+ ports support 10GBASE-CR, AOC, SR, LR, ER, ZR and DWDM optics, 10GBASE-T copper modules and 1GbE SX/LX/TX. The QSFP100 ports support 100GBASE and 40GBASE optics, AOC, CR4 and 4x10G or 4x25G breakout cables.
Q: What does the -F suffix mean?
A: The -F suffix denotes front-to-rear airflow with two AC power supplies and the FAN-7011M-F/R fan tray. The series also offers a rear-to-front airflow version, which is a different SKU.
Q: Which EOS release is required?
A: The minimum EOS release for this switch is 4.30.4.
