• Cisco WS-C2960CX-8TC-L switch with 8 yellow ports and 2 blue Gigabit uplinks
1 1

Cisco

Cisco WS-C2960CX-8TC-L | Catalyst 2960-CX 8-Port Gigabit Switch, LAN Base

WS-C2960CX-8TC-L

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 2960-CX is a compact, fanless, non-PoE Layer 2 managed switch with 8 x 10/100/1000 access ports and four Gigabit uplinks, made up of 2 copper ports and 2 SFP ports. It ships with the LAN Base feature set and delivers line-rate Gigabit forwarding in a small footprint. Ideal for space-constrained wiring closets, desktops and small branch deployments where PoE is not required.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Compact, fanless design for space-constrained deployments
- Line-rate Gigabit forwarding performance
- Managed Layer 2 switching with LAN Base feature set
- Dual console ports (RJ-45 and USB mini-B), with USB mini-B taking priority when both are connected
- Energy-efficient design with EEE support

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 8 x 10/100/1000 Gigabit Ethernet ports
- Uplinks: 2 x 1G copper plus 2 x 1G SFP
- No PoE output (non-PoE)
- Default software: LAN Base
- Forwarding bandwidth: 12 Gbps
- Switching bandwidth (full-duplex): 24 Gbps
- Forwarding rate (64-byte packets): 17.9 Mpps
- DRAM: 512 MB; Flash: 128 MB
- Max VLANs: 255; VLAN IDs: 4000
- Jumbo frames: 9198 bytes
- Dimensions (H x W x D): 4.44 x 26.9 x 21.3 cm (1.75 x 10.6 x 8.4 in)
- Weight: 1.72 kg (3.8 lb)
- Console: RJ-45 and USB mini-Type B; USB Type-A port
- Power consumption at 100% throughput: 18.8 W; MTBF 756,260 hours

FAQs

Q: Does this switch provide PoE?
A: No. The WS-C2960CX-8TC-L is a non-PoE model, so it does not supply power to connected devices. Choose a PoE variant of the 2960-CX if you need to power access points or phones.

Q: What uplink options does it have?
A: It has four 1G uplinks: two copper ports and two SFP ports, allowing a mix of copper and fibre connections upstream.

Q: Which software feature set does it run?
A: It runs the LAN Base feature set, which provides managed Layer 2 switching suited to access-layer deployments.

Q: Is the switch fanless?
A: Yes. It uses a compact, fanless design, which makes it suitable for quiet or space-constrained environments.

Q: How can I connect to the console?
A: It provides both an RJ-45 console port and a USB mini-Type B console port. If both are connected, the USB mini-B port takes priority.
