Cisco CSF6K-XNM-8X1GF | Secure Firewall 6100 8-Port 1G Copper Bypass Module

CSF6K-XNM-8X1GF

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Secure Firewall 6100 8-port 1000Base-T hardware bypass network module adds copper Gigabit Ethernet connectivity to Cisco Secure Firewall 6100 series chassis. It suits inline deployments, such as IPS or firewall placement in the data path, where traffic must keep passing on copper 1GbE links if the firewall fails or loses power.

The module provides eight RJ-45 1000Base-T ports arranged as four hardware bypass pairs: ports 1 and 2, 3 and 4, 5 and 6, and 7 and 8. When a failure event occurs, traffic is routed straight to the paired port without being processed by the firewall. Four bypass status LEDs (B1 to B4) show standby in green and flash amber when a pair is in bypass mode, and each port has left and right link and activity LEDs. The copper ports need no SFP transceivers.

It installs in network module slot NM-2 or NM-3 on the front panel of the Secure Firewall 6160 and 6170 chassis and is powered from the chassis. It works with Cisco Secure Firewall Threat Defense and Cisco Secure ASA software, and the correct firmware package and software release must be installed to support the module.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hardware bypass mode passes traffic to the paired port without firewall processing when a failure occurs
- Four paired-port bypass groups, each with a dedicated status LED
- Per-port link and activity LEDs plus a module power LED
- Captive screw and handle for installation in the chassis front panel
- Removable I/O module that adds eight copper Gigabit ports to the 6100 chassis
- Copper RJ-45 ports with no SFP transceivers needed

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Product ID: CSF6K-XNM-8X1GF
- Module type: Hardware bypass network module
- Ports: 8 x 1000Base-T (RJ-45 copper)
- Hardware bypass pairs: ports 1-2, 3-4, 5-6, 7-8
- Port numbering: top to bottom, left to right (Ethernet 2/1-2/8 in slot NM-2 or 3/1-3/8 in slot NM-3)
- Bypass LEDs: B1 to B4 (green = standby, flashing amber = port in hardware bypass mode)
- Port LEDs: left and right per port (unlit = no connection, green = link up, flashing green = activity)
- Chassis network module slots: two (NM-2 and NM-3) on the front panel
- Compatible chassis: Secure Firewall 6160 and 6170 (2 RU, 19-inch rack)
- Supported software: Cisco Secure Firewall Threat Defense and Cisco Secure ASA software
- Power: supplied by the chassis, no separate power supply

FAQs

Q: Which chassis does this module fit?
A: It installs in network module slot NM-2 or NM-3 of the Cisco Secure Firewall 6160 and 6170 chassis.

Q: Does the module need a licence?
A: The module itself has no separate licence. The chassis it installs in runs Cisco Secure Firewall Threat Defense or ASA software and is licensed at the chassis and software level.

Q: How does hardware bypass work?
A: Ports are paired as 1-2, 3-4, 5-6 and 7-8. If the firewall fails or loses power, traffic is passed directly between the paired ports without being processed by the firewall.

Q: Do I need SFP transceivers for the ports?
A: No. The eight ports are RJ-45 1000Base-T copper, so standard Ethernet cabling connects directly.

Q: Does it need its own power supply?
A: No. The module is powered from the Secure Firewall 6100 chassis.
