Cisco CSF6K-XNM-6X1SXF | Secure Firewall 6100 6-Port 1G SX Bypass Module

CSF6K-XNM-6X1SXF

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This network module expands a Cisco Secure Firewall 6100 series chassis (CSF-6160 or CSF-6170) with six 1-Gbps SX multimode fibre ports. It is built for inline threat-defence and IPS deployments in data centres and at the enterprise network edge, where traffic must keep flowing over multimode fibre even if the firewall fails or loses power.

The module provides six 1-Gbps SFP SX multimode ports with built-in SFP transceivers and an optical switch for hardware bypass, also called fail-to-wire. Ports are paired 1-2, 3-4 and 5-6, so traffic in bypass mode is forwarded between each pair at the physical layer without being processed by the firewall. The module supports passive, inline and inline-with-hardware-bypass interface configurations. The front panel carries a power LED, bypass LEDs B1 to B3 and six network activity LEDs.

It fits network module slots NM-2 and NM-3 and draws power from the chassis, so no separate power supply is needed. A firmware package and software version that support the module are required. The module itself needs no licence, although the host chassis runs Secure Firewall Threat Defense or ASA software with its associated feature subscriptions.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hardware bypass (fail-to-wire) keeps traffic flowing between paired ports if the appliance fails or loses power
- In bypass mode, traffic is forwarded between port pairs at the physical layer without firewall processing
- Supports passive, inline and inline-with-hardware-bypass interface configurations
- Built-in SFPs with an optical switch for bypass
- Network module design with captive screw and ejector handle
- Module must be disabled before removal and replaced with the same PID, then re-enabled

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Model: CSF6K-XNM-6X1SXF
- Description: 6-port 1-Gbps SFP SX multimode hardware bypass network module
- Port count: 6, numbered top to bottom, left to right
- Port speed: 1 Gbps
- Optics type: SX multimode, built-in SFP transceivers
- Hardware bypass pairs: ports 1 and 2, ports 3 and 4, ports 5 and 6
- Port naming: Ethernet 2/1 to 2/6 (slot NM-2) or Ethernet 3/1 to 3/6 (slot NM-3)
- Host chassis: Secure Firewall 6100 series (CSF-6160 / CSF-6170)
- Network module slots per chassis: two (NM-2 and NM-3)
- Front panel indicators: power LED, bypass LEDs B1 to B3, six network activity LEDs
- Transceiver hot swap and field replacement: not supported (built-in SFPs)
- Power: supplied by the chassis, no separate power supply

FAQs

Q: Does this module need a licence?
A: No licence is required for the module itself. The Secure Firewall 6100 chassis it plugs into runs Secure Firewall Threat Defense or ASA software and the associated feature subscriptions.

Q: Which chassis and slots does it fit?
A: It fits network module slots NM-2 and NM-3 of the Secure Firewall 6100 series (CSF-6160 and CSF-6170). It needs a firmware package and software version that support the module.

Q: Does it need its own power supply?
A: No. The module is powered from the Secure Firewall 6100 chassis.

Q: Which ports are paired for hardware bypass?
A: Ports 1 and 2, ports 3 and 4, and ports 5 and 6 form the bypass pairs. Each pair passes traffic at the physical layer when bypass is active.

Q: Can the SFPs be swapped in the field?
A: No. The SX multimode SFP transceivers are built in, and hot swapping or field replacement of the transceivers is not supported.

Q: How does it differ from the other hardware bypass modules?
A: This is the 6-port 1-Gbps SX multimode version. Sibling modules include the 6-port 10G and 25G SR and LR bypass modules (CSF6K-XNM-6X10SRF, -6X10LRF, -6X25SRF, -6X25LRF) and the 8-port CSF6K-XNM-8X1GF.
