Cisco CSF6K-XNM-4X200G | Secure Firewall 6100 4-Port 40/100/200G QSFP56 Module

CSF6K-XNM-4X200G

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco Secure Firewall 6100 4-port 40/100/200G network module adds high-bandwidth Ethernet connectivity to Secure Firewall 6100 Series appliances. It is built for data centre and campus edge firewall deployments that need 40, 100 or 200G links on the security perimeter.

The module provides four QSFP56 ports, each operating at 40, 100 or 200 Gbps with full-duplex Ethernet. Each 100-Gbps port can be split into four 10-Gbps or 25-Gbps interfaces using supported breakout cables, giving up to 16 x 10/25G interfaces per module. Ports are numbered Ethernet 2/1 to 2/4 or 3/1 to 3/4 depending on the network module slot it is installed in, and breakout interfaces follow the same scheme, for example Ethernet 2/1/1 to 2/4/4.

This module installs in a network module slot on the Secure Firewall 6100 Series chassis. It uses QSFP56 and QSFP optics together with supported breakout cables. Related modules in the same range include the CSF6K-XNM-4X40G 4-port 40G module and the CSF6K-XNM-2X100G 2-port 100G module.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Four QSFP56 ports in a single network module
- 40, 100 and 200-Gbps operation on every port
- Breakout of 100G ports into four 10G or 25G interfaces
- Up to 16 x 10/25G interfaces per module using breakout cables
- Installs in a network module slot on Secure Firewall 6100 Series appliances
- Suited to high-bandwidth data centre and campus edge firewall deployments

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Ports: 4 x QSFP56
- Port speeds: 40/100/200 Gbps per port
- Duplex: Full-duplex Ethernet
- Breakout: Each 100G port splits into 4 x 10G or 4 x 25G interfaces with supported breakout cables
- Maximum breakout interfaces: 16 x 10/25G per module
- Port numbering: Ethernet 2/1 to 2/4 or 3/1 to 3/4 depending on slot
- Breakout numbering: Ethernet 2/1/1 to 2/4/4 or 3/1/1 to 3/4/4
- Platform: Cisco Secure Firewall 6100 Series
- Installation: Network module slot on the chassis

FAQs

Q: Which firewalls does this module fit?
A: It is a network module for the Cisco Secure Firewall 6100 Series and installs in a network module slot on the chassis.

Q: Can the ports run at 10G or 25G?
A: Yes. Each 100-Gbps port can be split into four 10-Gbps or 25-Gbps interfaces using supported breakout cables, giving up to 16 x 10/25G interfaces per module.

Q: How does it differ from the other Secure Firewall 6100 modules?
A: This module has four QSFP56 ports supporting 40/100/200G. The CSF6K-XNM-4X40G offers four 40G QSFP/QSFP+ ports, and the CSF6K-XNM-2X100G offers two 100G QSFP56/QSFP28/QSFP ports.

Q: How are the ports numbered?
A: Ports appear as Ethernet 2/1 to 2/4 or 3/1 to 3/4 depending on which slot the module is installed in. Breakout interfaces extend this, for example Ethernet 2/1/1 to 2/4/4.
