Cisco CSF6K-XNM-2X400G | Secure Firewall 6100 2-Port 400G QSFP-DD Module

CSF6K-XNM-2X400G

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Secure Firewall 6100 2x400G QSFP-DD network module adds two 400G interfaces to the Cisco Secure Firewall 6160 and 6170 chassis. It suits data-centre, service-provider and large-enterprise edge deployments that need high-density 400G connectivity, and it fits one of the two network module bays in the chassis.

Each of the two QSFP-DD ports runs at 400 Gbps full-duplex Ethernet. Each port can also operate with 200G QSFP56, 100G QSFP28 or 40G QSFP+ transceivers, which lets you move to 400G in stages. Ports are numbered Ethernet 2/1 and 2/2, or 3/1 and 3/2 depending on the slot. The faceplate has a captive screw, a power-on LED, an ejector handle and per-port activity LEDs. This is a non-bypass module with no fail-to-wire function.

The module is powered from the host chassis, so it needs no separate power supply and carries no licence of its own. It runs under Secure Firewall Threat Defense or ASA software on the 6100 series, which carries its own licensing. It requires a compatible firmware package and software version on the host.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Adds up to 400G interfaces to the Secure Firewall 6100 series
- Each port also accepts 200G, 100G and 40G optics for staged upgrades
- Fits one of the two network module bays in the 6100 chassis
- Powered from the host chassis with no separate power supply
- Supported with Secure Firewall Threat Defense and ASA software on the 6100 series
- Per-port activity LEDs for quick link status checks

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Model (PID): CSF6K-XNM-2X400G
- Port count: 2
- Port type: QSFP-DD
- Native port speed: 400 Gbps
- Additional supported speeds per port: 200 Gbps (QSFP56), 100 Gbps (QSFP28), 40 Gbps (QSFP+)
- Duplex: Full-duplex Ethernet
- Port numbering: Ethernet 2/1 or 3/1 through Ethernet 2/2 or 3/2, left to right
- Front panel: captive screw, power-on LED, ejector handle, per-port network activity LEDs
- LED behaviour: off = no SFP, amber = no link or network failure, green = link up, flashing green = network activity
- LED note: in 40/100/200-Gbps mode only the left-most LED indicates link and activity
- Hardware bypass (fail-to-wire): No
- Chassis network module bays: 2 per Secure Firewall 6100 chassis
- Host chassis: Secure Firewall 6160 and 6170
- Power: supplied by the host chassis, no separate PSU

FAQs

Q: Does this module need its own licence?
A: No. The module itself needs no licence. The host Secure Firewall 6100 runs Threat Defense or ASA software, which carries its own licensing.

Q: Which chassis does it fit?
A: It fits the Cisco Secure Firewall 6160 and 6170 chassis only, in one of the two network module bays.

Q: Can the ports run below 400G?
A: Yes. Each port also supports 200G QSFP56, 100G QSFP28 and 40G QSFP+ transceivers. Check the installation guide's transceiver table for exact part numbers and first supported releases.

Q: How is the module powered?
A: It draws power from the host chassis, so no separate power supply is needed.

Q: How does it differ from the other 6100 network modules?
A: This is the 2-port 400G QSFP-DD module. Other 6100 modules offer 2x100G QSFP28, 4x200G QSFP56 or 4x40G QSFP+ ports.

Q: Does it support hardware bypass?
A: No. This is a non-bypass module, so it has no fail-to-wire function.
