Cisco CSF6K-XNM-2X100G | Secure Firewall 6100 2-Port 100G QSFP28 Module

CSF6K-XNM-2X100G

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This network module adds two QSFP28 ports to the Cisco Secure Firewall 6100 Series, covering the CSF6160 and CSF6170 chassis. It suits high-throughput data centre and campus edge firewalling where 40G or 100G uplinks are needed, or where 10G and 25G interfaces are required through breakout cables.

Each of the two ports runs at 40 Gbps or 100 Gbps, giving a maximum of 200 Gbps full duplex when both ports operate at 100 Gbps. A 100G port can be split into four 10G or four 25G interfaces using supported breakout cables. The ports are named Ethernet 2/1 and 2/2 in slot NM-2, or 3/1 and 3/2 in slot NM-3. The module itself needs no licence, as Threat Defense or ASA software licensing applies to the host chassis. It is supported from Threat Defense 10.0 and ASA 9.24.

Genuine supported 100G optics and cables include QSFP-100G-SR4-S, QSFP-100G-LR4-S, QSFP-100G-AOCxM and QSFP-100G-CUxM. Supported 40G options include QSFP-40G-SR4, QSFP-40G-LR4-S and QSFP-H40G-CUxM.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Adds 40G and 100G connectivity to the Secure Firewall 6100 chassis
- Breakout cables provide 10G and 25G interfaces from each 100G port
- Accepts QSFP, QSFP+ and QSFP28 optics and cables
- Per-port link and activity LEDs plus a power-on LED
- Captive screw and ejector handle for installation
- Hot-swappable with a module of the same type

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Part number: CSF6K-XNM-2X100G
- Ports: 2 x QSFP/QSFP28
- Port speeds: 40 Gbps and 100 Gbps
- Maximum bandwidth: 200 Gbps full duplex
- Breakout: each 100G port can split into 4 x 10G or 4 x 25G with supported breakout cables
- Port naming: Ethernet 2/1 and 2/2 (slot NM-2) or 3/1 and 3/2 (slot NM-3)
- Host chassis: Secure Firewall 6100 Series (CSF6160, CSF6170)
- Chassis network module slots: two (NM-2, NM-3), hot-swappable
- Hot-swap: same-type replacement supported, a different module type requires a chassis reboot
- First supported release: Threat Defense 10.0 / ASA 9.24
- Power: supplied by the host chassis

FAQs

Q: Does this module need its own licence?
A: No. The module itself needs no licence. Threat Defense or ASA software licensing applies to the host Secure Firewall 6100 chassis.

Q: Which firewalls does it work with?
A: It is supported in the Secure Firewall 6100 Series, covering the CSF6160 and CSF6170, from Threat Defense 10.0 or ASA 9.24.

Q: Which optics and cables are supported?
A: Supported 100G options include QSFP-100G-SR4-S, QSFP-100G-LR4-S, QSFP-100G-AOCxM and QSFP-100G-CUxM. Supported 40G options include QSFP-40G-SR4, QSFP-40G-LR4-S and QSFP-H40G-CUxM.

Q: Can I get 10G or 25G ports from it?
A: Yes. Each 100G port can be split into four 10G or four 25G interfaces using supported breakout cables such as QSFP-4SFP25G-CUxM.

Q: Can it be swapped while the firewall is running?
A: A module can be hot-swapped when replaced with the same module type. Changing to a different module type requires a chassis reboot.
