Cisco

Cisco CSF6100-SSD3600 | Secure Firewall 6100 3.6TB NVMe SSD, SED (non-FIPS)

CSF6100-SSD3600

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This 3.6 TB self-encrypting NVMe SSD module is built for the Cisco Secure Firewall 6100 Series. It is the storage drive fitted by default to the Secure Firewall 6160, so it suits replacement or spare storage for 6160 appliances. In the 6100 Series, the SSDs are used for event storage and malware analysis.

The module is a self-encrypting drive (SED) in the non-FIPS variant, with 3.6 TB of NVMe capacity. Each 6100 chassis has two SSD slots (SSD-1 and SSD-2), each holding one NVMe SSD. The two drives run in factory-configured software RAID1. The drive is hot-swappable, and the 'raid remove-secure local-disk 1|2' command is run before removal.

No licence is needed for the SSD itself, and it draws power from the chassis with no separate supply. It fits the Cisco Secure Firewall 6100 Series. The 6160 ships with two 3.6 TB SSDs, while the 6170 uses 7.2 TB drives.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Self-encrypting NVMe storage for event storage and malware analysis on the Secure Firewall 6100
- Hot-swappable without powering off the chassis
- Two SSDs run in factory-configured software RAID1
- 3.6 TB capacity per drive
- Fits either of the two NVMe SSD slots in the 6100 chassis

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Capacity: 3.6 TB
- Type: NVMe SSD module
- Encryption: Self-encrypting drive (SED), non-FIPS
- Compatible platform: Cisco Secure Firewall 6100 Series
- Default fit: Secure Firewall 6160
- SSD slots per chassis: 2 (SSD-1 and SSD-2)
- RAID: Software RAID1, factory-configured
- Hot swap: Supported
- Drive identifiers: disk0: and disk1:
- Power: Supplied by the chassis, no separate power supply

FAQs

Q: Does this SSD need a licence?
A: No licence is required for the SSD itself. The firewall it installs in uses its own Secure Firewall software and subscription licences.

Q: Which firewalls does it work with?
A: It is made for the Cisco Secure Firewall 6100 Series. It is the drive fitted by default to the Secure Firewall 6160, which ships with two 3.6 TB SSDs.

Q: Can it be replaced while the firewall is running?
A: Yes, the drive is hot-swappable. Run 'raid remove-secure local-disk 1|2' for the relevant slot before removing it.

Q: How does this differ from the FIPS version?
A: This SKU is the self-encrypting 3.6 TB drive in its non-FIPS form. The FIPS-compliant 3.6 TB drive is a separate SKU, CSF6100-SSD3600-F.

Q: How many SSDs does the chassis hold?
A: The 6100 chassis has two NVMe SSD slots, SSD-1 and SSD-2. The two drives run in software RAID1.
