• Stack of five silver arista ccs-722xpm-48zy8-f 48-port 2.5g poe+ network switches with black ethernet ports
1 1

Arista

Arista CCS-722XPM-48ZY8-F | 722XPM 48-Port 2.5G PoE+ Switch, 890W, 8x 25G SFP28

CCS-722XPM-48ZY8-F

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Arista CCS-722XPM-48ZY8-F is a high-performance campus PoE+ switch designed for IoT-enabled enterprise environments. Featuring 48x multigigabit 2.5G RJ45 ports with 60W PoE++ per port and 8x 25G SFP28 uplinks, it delivers 640 Gbps full-duplex switching capacity with MACsec encryption on all ports. Running Arista EOS with CloudVision integration, this 1RU switch supports advanced Layer 2/3 features, real-time telemetry, and zero-touch provisioning for modern cognitive campus deployments.

Features

Arista EOS single-image operating system with cognitive campus features
- Layer 2: RPVST+, MSTP, 4096 VLANs (1024 active), Q-in-Q, 802.3ad LACP
- Layer 3: Static routing, OSPF, BGP, IS-IS, PIM, VXLAN/EVPN
- VRF support for network segmentation and multi-tenancy
- Dynamic PoE power management with priority-based allocation
- Persistent PoE maintains power during switch reboot
- FlowTracker: Real-time application and device flow monitoring
- Device fingerprinting: Automatic device type and OS identification
- sFlow and IPFIX for network telemetry and analytics
- CloudVision integration for zero-touch provisioning and automation
- Advanced security: 802.1X, MACSec, 12K ingress ACLs, AAA, RADIUS/TACACS+
- Jumbo frame support up to 9216 bytes
- Hot-swappable redundant power supplies and fan modules
- Load-sharing power supply architecture for optimized PoE allocation
- Support for 1G/10G/25G SFP/SFP+ and SFP28 transceivers
- Front-to-rear or rear-to-front airflow options for flexible data center cooling
- Standards compliance: IEEE 802.3, 802.3ab, 802.3bz, 802.3by, 802.3af/at/bt, RoHS

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

48x 2.5G multigigabit RJ45 ports (100M to 2.5GbE auto-negotiation)
- 8x 25G SFP28 uplink ports
- PoE++ 802.3bt support: up to 60W per port
- PoE power budget: 890W with single PSU / 1835W with dual PSU (PWR-1021-AC-RED)
- Switching capacity: 640 Gbps full-duplex
- Forwarding rate: 952 Mpps
- Latency: <1.2 microseconds
- Packet buffer: 8 MB
- System memory: 4 GB
- MAC address table: 64,000 entries
- MACsec 256-bit encryption on all ports
- Power consumption: 134W typical / 160W maximum (excluding PoE)
- Front-to-rear airflow (F suffix)
- Management: Arista EOS, CLI, SNMPv3, SSHv2, HTTPS, CloudVision
- Hot-swappable dual redundant power supplies and fans
- Operating temperature: 0°C to 40°C
- 1RU rack-mountable form factor

FAQs

Q: What is the maximum PoE power budget available?
A: The CCS-722XPM-48ZY8-F provides 890W PoE budget with a single 1050W AC PSU, or up to 1835W with dual redundant PSUs. Each of the 48 ports supports up to 60W per port via 802.3bt PoE++, ideal for powering high-performance Wi-Fi 6/6E access points, PTZ cameras, and IoT devices.

Q: Does this switch support MACsec encryption?
A: Yes, the CCS-722XPM-48ZY8-F includes hardware-based 256-bit MACsec encryption on all downlink and uplink ports, providing layer-2 data plane security to protect against eavesdropping in zero-trust campus environments without impacting performance.

Q: What is CloudVision and is it required?
A: CloudVision is Arista's optional cloud-based or on-premises network management platform that provides zero-touch provisioning, real-time telemetry, automated compliance, and predictive analytics. While not required, it significantly simplifies deployment and ongoing operations. The switch runs Arista EOS and can be managed via CLI, SNMP, or traditional methods.

Q: Can this switch be used for Wi-Fi 6 AP deployments?
A: Absolutely. The 48x 2.5G multigigabit ports with 60W PoE++ per port are specifically designed for high-density Wi-Fi 6/6E access point deployments, providing both the bandwidth and power required for modern wireless infrastructure while the 8x 25G uplinks ensure non-blocking aggregation.

Q: What routing and Layer 3 capabilities does it support?
A: The CCS-722XPM-48ZY8-F supports advanced Layer 3 routing with up to 16K IPv4 routes and 6K IPv6 routes. Routing protocols include OSPF, BGP, IS-IS, and VXLAN/EVPN for campus fabric deployments. Advanced licenses unlock full routing tables and additional features. It also supports VRFs for multi-tenancy and network segmentation.
