• Stack of five silver arista ccs-722xpm-48y4-r gigabit poe+ switches with 48 ports and sleek metallic chassis
1 1

Arista

Arista CCS-722XPM-48Y4-R | 722XPM 48-Port Gigabit PoE+ Switch, 967W, 4x 25G, 4x 10G

CCS-722XPM-48Y4-R

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Arista CCS-722XPM-48Y4-R is a campus switch delivering wire-speed connectivity with MACsec encryption on all ports for IoT-enabled enterprise environments. Featuring 48 Gigabit PoE+ ports with up to 967W total PoE budget and high-speed uplinks, it supports advanced Layer 2/3 routing protocols and VXLAN overlay networking. Running Arista EOS with cognitive campus services, it provides real-time telemetry, automated deployment, and seamless integration with CloudVision management for modern network visibility and security.

Features

48-port Gigabit Ethernet with 802.3at PoE+ (30W per port)
- High-speed uplinks: 4x 25GbE SFP28 and 4x 10GbE SFP+ ports
- 376 Gbps total switching capacity
- Hardware-accelerated MACsec 256-bit AES encryption on all ports
- 802.1X port-based network access control with dynamic encryption
- Layer 2 features: 802.1Q VLANs, 802.1w RSTP, 802.1s MSTP
- Layer 3 routing: OSPF, BGP, RIP-2, static routes, IPv4/IPv6
- VXLAN/EVPN (Type 2/5) for overlay networking and segmentation
- IPv4/IPv6 VRF-lite for multi-tenancy and traffic isolation
- MLAG for active-active link aggregation and redundancy
- Dynamic uplink load balancing
- Hardware-accelerated sFlow, IPFIX, and FlowTracker telemetry
- ISSU (In-Service Software Upgrade) for hitless upgrades
- 1+1 redundant hot-swappable power supplies
- N+1 hot-swappable fans with configurable airflow direction
- Arista EOS with stateful fault repair (SFR) and containment (SFC)
- Extensible OS: full Linux shell, Python, C++, GO, OpenConfig
- CloudVision integration for network-wide automation and analytics
- Rear-to-front airflow for hot aisle data center deployment
- RoHS and WEEE compliant

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

48x 10/100/1000BASE-T PoE+ RJ45 ports, 30W per port
- 4x 25G SFP28 uplink ports
- 4x 10G SFP+ uplink ports
- 376 Gbps switching bandwidth
- Default PoE power budget: 967W with single 1050W PSU
- Maximum PoE budget: 1860W with dual 1050W PSUs
- MACsec 256-bit encryption on all ports, 50Gbps performance
- System power consumption: 83W typical, 102W maximum (excluding PoE)
- 1.2 microsecond latency
- Supports jumbo frames up to 9216 bytes
- 4GB system memory, 8MB packet buffer
- Rear-to-front (reverse) airflow for hot aisle deployment
- 1RU rack-mountable, dimensions: 44.5 x 4.4 x 36.4 cm (17.5 x 1.75 x 14.5 inches)
- Weight: 6.8 kg (15 lbs)
- Operating temperature: 0°C to 40°C
- Redundant hot-swappable power supplies (1+1)
- Three hot-swappable field-replaceable fans
- AC power supply: PWR-1021-AC-RED or PWR-621-AC-BLUE (sold separately)
- Management: CLI, web GUI, SNMP, sFlow, IPFIX
- Arista EOS single binary image operating system

FAQs

Q: Does this switch require a separate license for full functionality?
A: The CCS-722XPM-48Y4-R ships with base Arista EOS functionality included. Advanced features like full Layer 3 routing beyond 32K routes, EVPN, and VXLAN require optional FLX-Lite or FlexRoute feature licenses. CloudVision management is available as a subscription service.

Q: What does the -R suffix mean in the model number?
A: The -R suffix indicates rear-to-front (reverse) airflow, designed for hot aisle exhaust deployment in data centers. This model uses blue-handled fans and power supplies. The standard -F variant has front-to-rear airflow with red-handled components for cold aisle intake.

Q: Does this switch include power supplies and fans?
A: The CCS-722XPM-48Y4-R requires power supplies and fans to be ordered separately. It supports one or two PWR-1021-AC-RED (1050W) or PWR-621-AC-BLUE power supplies for redundancy, and ships with three hot-swappable fans matched to the reverse airflow configuration.

Q: Can this switch be used for IoT and campus edge deployments?
A: Yes, the 722XPM series is specifically designed for IoT-enabled campus environments. It provides 802.1X authentication, dynamic MACsec encryption, VLAN segmentation, and integrates with Arista Cognitive Campus services for automated device onboarding, visibility, and threat detection across user desktops, PoE appliances, and IoT devices.

Q: What routing protocols does this switch support?
A: The CCS-722XPM-48Y4-R supports OSPF, BGP, RIP-2, and static routing protocols. It also supports advanced campus features including MLAG for active-active redundancy, VXLAN/EVPN for overlay networking, VRF-lite for traffic segmentation, and FlowTracker for device inventory and conversation monitoring.
