• Stack of five silver arista ccs-722xpm-48y4-2r 48-port gigabit poe+ network switches with black ethernet ports
1 1

Arista

Arista CCS-722XPM-48Y4-2R | 722XPM 48-Port Gigabit PoE+ Switch, 967W, 4x 25G, 4x 10G

CCS-722XPM-48Y4-2R

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Arista CCS-722XPM-48Y4-2R is a high-performance campus PoE+ switch designed for enterprise and cognitive campus deployments. Featuring 48 Gigabit Ethernet ports with 30W PoE per port, 4x 25G SFP28 and 4x 10G SFP+ uplinks, and 376 Gbps switching bandwidth, this switch delivers wire-speed connectivity with MACsec encryption on all ports. Part of the Arista 722XPM Series, it includes dual redundant power supplies, rear-to-front airflow, and runs on Arista EOS for advanced network automation and telemetry.

Features

Full Layer 2 and Layer 3 switching with OSPF, BGP, RIP-2 routing protocols
- MACsec 256-bit AES static and dynamic encryption on all ports
- 802.1x network access control and port-based authentication
- VXLAN overlay networking with EVPN Layer 2/3 support (type 2/5)
- Active/Active MLAG for multi-chassis link aggregation and redundancy
- Dynamic uplink load balancing with L3 ECMP
- FlowTracker for hardware-accelerated device inventory and conversation monitoring
- sFlow and IPFIX for traffic monitoring and analytics
- Device fingerprinting to identify device type, OS, and user ID
- CloudVision integration for centralized management and telemetry
- 802.1Q VLAN support with IPv4/IPv6 VRFs for segmentation
- 802.1w Rapid Spanning Tree and 802.1s Multiple Spanning Tree Protocol
- In-Service Software Upgrade (ISSU) for hitless patching
- Stateful Fault Containment and Stateful Fault Repair
- Arista EOS single binary modular operating system
- Open programmability with Python, Bash, C++, Go, and OpenConfig
- Full Linux shell access for custom automation and scripting
- N+1 redundant power and cooling with hot-swappable PSUs and fans
- Support for 1G, 10G, and 25G multi-rate pluggable optics

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

48x 10/100/1000BASE-T RJ45 ports with 30W PoE per port
- 4x 25G SFP28 uplink ports
- 4x 10G SFP+ uplink ports
- Switching bandwidth: 376 Gbps
- MACsec performance: 50 Gbps downlinks, 50 Gbps uplinks
- Default PoE budget: 967W (single 1050W PSU)
- Maximum PoE budget: 1,860W (dual 1050W PSU)
- System power consumption: 83W typical / 102W maximum (excluding PoE)
- Latency: 1.2 microseconds
- Jumbo frame support: up to 9,216 bytes
- Memory: 4 GB system memory
- Packet buffer: 8 MB
- Dual redundant hot-swappable power supplies (1+1 redundancy)
- Three hot-swappable field-replaceable fans
- Rear-to-front airflow design
- Operating temperature: 0°C to 40°C
- Form factor: 1RU rack-mountable
- Management: Arista EOS, CLI, CloudVision
- Compliance: RoHS, WEEE

FAQs

Q: What PoE standard does the CCS-722XPM-48Y4-2R support?
A: The switch supports IEEE 802.3af/at PoE/PoE+ with 30W per port across all 48 Gigabit Ethernet ports, providing up to 967W PoE budget with a single 1050W power supply or up to 1,860W with dual power supplies.

Q: What is the difference between the -2R and -2F suffix models?
A: The -2R suffix indicates rear-to-front airflow with dual power supplies, while -2F indicates front-to-rear airflow with dual power supplies. The airflow direction should match your data center hot/cold aisle design for optimal cooling efficiency.

Q: Does this switch support Layer 3 routing?
A: Yes, the 722XPM-48Y4 supports Layer 3 routing protocols including OSPF, BGP, and RIP-2. Advanced features such as EVPN, VXLAN, and VRFs may require additional feature licenses through Arista's FlexRoute or FlexAdvance license packages.

Q: What makes this a cognitive campus switch?
A: The 722XPM Series integrates with Arista CloudVision for advanced telemetry, FlowTracker for real-time device and application flow monitoring, device fingerprinting, and automated network configuration. It tracks over 1,000 concurrent flows per switch with hardware support for up to 32K flows.

Q: Is MACsec encryption included or does it require a license?
A: MACsec 256-bit AES encryption is built into the switch hardware and supported on all ports at line rate (50 Gbps downlinks, 50 Gbps uplinks), providing end-to-end encryption for secure campus deployments.
