• Stack of five silver arista ccs-720dp-24s-m-s-2f 720d 24-port gigabit poe+ switches with ethernet ports
1 1

Arista

Arista CCS-720DP-24S-M-S-2F | 720D 24-Port Gigabit PoE+ Switch, 720W, 4x 10G SFP+

CCS-720DP-24S-M-S-2F

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Arista CCS-720DP-24S-M-S-2F is a compact 1RU campus switch designed for IoT-enabled enterprise networks. It delivers 24 ports of Gigabit Ethernet with 802.3af/at/bt PoE support, providing up to 30W per port with a total power budget of 720W. Featuring expanded memory, 4x 10G SFP+ uplinks, redundant 460W power supplies, and front-to-rear airflow, this Layer 2/3 switch runs Arista EOS for simplified campus management and advanced segmentation capabilities.

Features

Arista EOS operating system with modular architecture and state sharing
- Multi-Chassis Link Aggregation (MLAG) for active-active uplink redundancy
- Hardware-based VXLAN de-encapsulation for WiFi traffic segmentation
- Wire-speed Layer 3 VRF segmentation for sophisticated campus use cases
- 802.1X and RADIUS authentication with automatic VLAN assignment
- Support for 509 active VLANs and Q-in-Q tunneling
- IGMP v1/v2/v3 snooping and PIM multicast routing
- Bidirectional Forwarding Detection (BFD) for fast convergence
- Storm control and broadcast suppression
- Front-to-rear airflow design for efficient cooling in campus closets
- Redundant power supplies with hot-swap capability
- Mode button for hard reset and factory reset
- Compact 1RU form factor for space-efficient deployment
- Cognitive campus services integration for automation and visibility
- Unified management across spline, leaf, and wireless platforms

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

24x 1GigE (10M-1G) RJ45 ports with PoE+ support
- 802.3af/at/bt PoE: 30W per port, 720W total budget
- 4x 10G SFP+ uplinks (1G/10G compatible)
- Switching capacity: 128 Gbps
- Forwarding rate: 95 Mpps
- Latency: 1.2 microseconds
- Memory: 4GB RAM (expanded), 8GB Flash
- MAC address table: 32,000 entries
- VLANs: 4096 total, 509 active
- Routing: 4,000 IPv4 routes, 6,000 IPv6 routes
- IGMP groups: 32,000
- VXLAN tunnel termination: 1,000 VTEPs
- Layer 2: RSTP, MSTP, RPVST+, MLAG, LACP, jumbo frames (9216 bytes)
- Layer 3: OSPF, BGP, IS-IS, RIPv2, 64-way ECMP, VRF, PIM, BFD
- Security: 802.1X, RADIUS, VXLAN segmentation
- Management: CLI, Web UI, SNMP, Arista CloudVision (SaaS)
- Power: Dual redundant 460W AC power supplies, front-to-rear airflow
- Dimensions: 1RU, 17.2" W x 10.5" D x 1.7" H
- Operating temperature: 0°C to 45°C
- Certifications: UL, CE, FCC Class A

FAQs

Q: What is the total PoE power budget for this switch?
A: The CCS-720DP-24S-M-S-2F provides a total PoE budget of 720W across all 24 ports, with each port supporting up to 30W via 802.3af/at/bt standards. This is sufficient to power high-wattage devices such as Wi-Fi 6 access points, PTZ cameras, and VoIP phones simultaneously.

Q: What does the M-S designation mean in the model number?
A: The M-S indicates that this model includes expanded memory (8GB flash instead of 4GB) and dual power supply slots for redundancy. The expanded memory allows for advanced features and larger routing tables, making it ideal for complex campus deployments.

Q: Can this switch be managed via cloud-based platforms?
A: Yes, the switch runs Arista EOS and integrates with Arista CloudVision, a cloud-managed SaaS platform that provides centralized management, monitoring, automation, and telemetry across your entire campus network infrastructure.

Q: Does this switch support Layer 3 routing and VXLAN?
A: Yes, the 720DP-24S supports full Layer 3 routing with protocols including OSPF, BGP, IS-IS, and 64-way ECMP. It also supports VXLAN tunnel termination for up to 1,000 virtual tunnel endpoints, enabling advanced network segmentation and overlay networks.

Q: What uplink speeds are supported on the SFP+ ports?
A: The 4x SFP+ uplink ports support both 1G and 10G speeds, providing flexibility to connect to existing 1G infrastructure or upgrade to 10G for high-bandwidth aggregation and campus spine connectivity.
