Juniper EX8216-CHAS-S | EX8200 16-Slot Switch Chassis, Passive Midplane, Spare

EX8216-CHAS-S

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The EX8216-CHAS-S is a spare 16-slot modular chassis with a passive midplane for the Juniper EX8200 Series EX8216 Ethernet Switch. It suits high-density data centre aggregation, campus aggregation and core switching, and is the right part for sparing, expansion or field replacement of an existing EX8216. This SKU is the chassis with passive midplane only, with no Routing Engines, switch fabric modules, fan trays, power supplies or line cards.

In a fully configured EX8216 the chassis supports up to 768 x 1GbE or 128 x 10GbE wire-speed ports and a system capacity of up to 12.4 Tbps, with approximately 1.9 Bpps of packet forwarding. It occupies 21 RU (half rack), so two chassis fit in a 42U rack. The chassis accepts 1 or 2 Routing Engines, 8 switch fabric modules, 2 fan trays with 9 fans each, and up to 6 AC or DC power supplies.

The chassis works with EX8200 line cards, EX8216 fan trays (EX8216-FAN-S), EX8200 Routing Engines, EX8216 switch fabric modules, 2000 W and 3000 W AC and 3000 W DC power supplies, and the XRE200 External Routing Engine for EX8200 Virtual Chassis. It is 19-inch rack mountable.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Modular 16-slot design for scalable core and aggregation switching
- Passive midplane carries control, management and power signals, with data-plane signals running directly from line cards to fabric modules
- Hot-insertable and hot-removable Routing Engines, fabric modules, fan trays and power supplies
- Redundant, load-sharing power supplies and redundant variable-speed fans
- Shares EX8200 line cards and power supplies with the EX8208
- Supports EX8200 Virtual Chassis through the XRE200 External Routing Engine
- Chassis-level LCD panel for status, alarms and initial configuration

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Part number: EX8216-CHAS-S
- Chassis: 16-slot modular enclosure with passive midplane
- Rack units: 21 RU (half rack)
- Expansion slots: 16
- Max Gigabit Ethernet density: 768 ports (fully configured)
- Max 10-Gigabit Ethernet density: 128 ports (fully configured)
- System capacity: up to 12.4 Tbps (fully configured)
- Packet forwarding: approx. 1.9 Bpps (fully configured)
- Routing Engines supported: 1 or 2
- Switch fabric modules: 8, all active, installed in rear slots SF7-SF0
- Fan trays: 2 hot-insertable trays, 9 fans each, top and bottom interchangeable
- Power supplies supported: up to 6 AC or DC, load-sharing and redundant (2000 W AC, 3000 W AC, 3000 W DC)
- Cooling airflow: side-to-side and front-to-side
- Management: chassis-level LCD panel, CLI, J-Web, NSM
- Operating system: Junos OS (on installed Routing Engine)
- Layer support: Layer 3 via Junos OS

FAQs

Q: Does the EX8216-CHAS-S need a licence?
A: The chassis itself needs no licence. Junos OS runs on the installed Routing Engine, and any advanced feature licences are tied to the Routing Engine or system rather than this spare chassis.

Q: Which power supplies does the chassis use?
A: It accepts up to six hot-swappable AC or DC power supplies: 2000 W AC, 3000 W AC or 3000 W DC. These are ordered separately.

Q: What do I need to add to make a working switch?
A: You need at least one Routing Engine, the switch fabric modules, fan trays, power supplies and your choice of EX8200 line cards. This SKU is the chassis with passive midplane only.

Q: Which line cards and modules does it work with?
A: It works with EX8200 line cards such as the EX8200-48T, EX8200-48F and EX8200-8XS, EX8216 fan trays (EX8216-FAN-S), EX8200 Routing Engines and EX8216 switch fabric modules.

Q: Can it be used in an EX8200 Virtual Chassis?
A: Yes. The EX8216 supports EX8200 Virtual Chassis through the XRE200 External Routing Engine.
