• HPE JL823A black Cisco switch with 24x 1G PoE+ ports and 2x 10G uplinks
1 1

Aruba

Aruba JL823A | FlexNetwork 5140 24-Port PoE+ Switch, 370W, 2x SFP+

JL823A

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The FlexNetwork 5140 EI is a Layer 2 Gigabit access switch built for the access layer of medium and large enterprise campuses and branches. It powers IP phones, wireless access points and cameras over PoE+ and runs the Comware operating system.

This model provides 24 autosensing 10/100/1000 PoE+ RJ-45 ports (IEEE 802.3at) with a 370W PoE budget. Four fixed 10GbE uplinks are included: 2x SFP+ and 2x 10GBASE-T. Switching capacity is 128 Gbps with a forwarding rate of 95.23 Mpps. IRF stacking delivers up to 80 Gb/s of stacking bandwidth, and the switch supports static Layer 3 routing and RIP. This SKU ships with the EI (Enhanced Image) software, so no separate licence is needed to operate it.

It stacks with other 5140 EI switches using IRF. The SFP+ uplinks accept SFP+ transceivers and DACs, and the 10GBASE-T uplinks take standard RJ-45 copper cabling. The 1U chassis is rack-mountable.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Static Layer 3 routing and RIP on a Gigabit PoE+ access switch
- HPE Intelligent Resilient Fabric (IRF) stacking for device aggregation and link aggregation across multiple switches
- Embedded network management through Smart Management Center (SmartMC) at no additional cost
- Energy-saving design with idle port power saving, powering down of unused ports and Energy Efficient Ethernet support
- Enterprise-class QoS and security, including ACLs and IPv6
- Link redundancy with MSTP, RSTP, PVST+, RPVST+ and ECMP
- PoE+ on all 24 access ports for IP phones, wireless access points and cameras

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Fixed ports: 24 x RJ-45 autosensing 10/100/1000 PoE+ (IEEE 802.3at)
- Uplink ports: 2 x 10GbE SFP+ and 2 x 10GBASE-T
- PoE power budget: 370W
- Switching capacity: 128 Gbps
- Forwarding rate: 95.23 Mpps
- IRF stacking bandwidth: up to 80 Gb/s
- Software image: EI (Enhanced Image), Comware OS
- Form factor: 1U rack-mountable
- Power supply: internal AC

FAQs

Q: Does this switch need a separate software licence?
A: No. The EI (Enhanced Image) software is included with this SKU, so no separate licence is needed to operate it. Embedded SmartMC management has no additional cost.

Q: How much PoE power does it provide?
A: It has a 370W PoE budget shared across 24 PoE+ ports, with up to 30W per port under IEEE 802.3at.

Q: What can I connect to the 10G uplinks?
A: The two SFP+ ports accept SFP+ transceivers and DACs, and the two 10GBASE-T ports take standard RJ-45 copper cabling.

Q: Can it be stacked with other switches?
A: Yes. It supports IRF stacking with other 5140 EI switches, with up to 80 Gb/s of stacking bandwidth.

Q: What operating system does it run?
A: It runs Comware, with static Layer 3 routing and RIP supported.
