• HPE JH324A 48-port black Gigabit Ethernet switch with 4x 10G SFP+ uplinks
1 1

HPE

HPE JH324A | FlexNetwork 5130 HI 48-Port Gigabit L3 Switch, 4x 10G SFP+

JH324A

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The FlexNetwork 5130 HI JH324A is a Layer 3 managed Gigabit access-layer switch built for the access layer of medium and large enterprise campus networks, where routing, stacking and 10GbE uplinks are needed in a single 1U chassis.

It provides 48 autosensing 10/100/1000 RJ45 ports, with MACsec supported on ports 1-8, plus 4 x 10GbE SFP+ uplinks and one interface module slot for expansion. Switching capacity is 216 Gbps with throughput of up to 190.5 Mpps, backed by 2 GB SDRAM, 512 MB flash and a 4 MB packet buffer. This is a non-PoE model, powered by an internal AC supply with a typical draw of 70 W and a maximum of 150 W.

The expansion slot accepts optional HI interface modules, taking the switch to a maximum of 6 SFP+ ports or 2 x 1/10GBASE-T ports. IRF stacking lets up to 9 switches operate as one virtual device, and management is available through HPE IMC, CLI, web browser and SNMP.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Layer 3 routing and switching for the campus access layer
- IRF stacking to virtualise up to 9 switches as one device
- MACsec encryption on ports 1-8
- Modular expansion slot for additional SFP+ or 10GBASE-T ports
- Managed through HPE IMC, CLI, web browser and SNMP
- Jumbo frame and ACL support

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Ports: 48 x RJ45 autosensing 10/100/1000
- MACsec: supported on ports 1-8
- Uplink ports: 4 x 10GbE SFP+
- Expansion: 1 interface module slot
- Layer: Layer 3 managed
- PoE: No
- Switching capacity: 216 Gbps
- Throughput: up to 190.5 Mpps
- Memory and processor: 2 GB SDRAM
- Packet buffer size: 4 MB
- Flash memory: 512 MB
- Latency (1 Gbps): less than 5 microseconds
- Latency (10 Gbps): less than 3 microseconds
- MAC address table size: 32768 entries
- Routing table size: 32768 entries (IPv4), 16384 entries (IPv6)
- Stacking: IRF, up to 9 switches
- Jumbo frames: Yes
- Management: IMC, CLI, web browser, SNMP
- Input voltage: 100-240 VAC rated
- Power consumption: 70 W typical, 150 W maximum
- Heat dissipation: 419 BTU/hr
- Dimensions (H x W x D): 43.7 x 440 x 360 mm
- Weight: 7.5 kg
- Form factor: 1U rack-mount
- Operating temperature: 0 to 45 C
- Storage temperature: -40 to 70 C
- Operating humidity: 10 to 90% non-condensing

FAQs

Q: Does this switch provide PoE?
A: No. The JH324A is a non-PoE model, so powered devices such as access points or IP phones need a separate PoE source.

Q: Does the JH324A need a separate licence?
A: No separate licence is required to use the Layer 3 feature set of this model.

Q: How can I add more uplink ports?
A: The interface module slot accepts optional HI modules, giving a maximum of 6 SFP+ ports or 2 x 1/10GBASE-T ports in total.

Q: How many switches can be stacked together?
A: IRF stacking supports up to 9 switches operating as a single virtual device.

Q: What optics work in the SFP+ ports?
A: The SFP+ ports accept 10GbE SFP+ optics and direct attach cables.
