Cisco WS-C3750X-24P-L | Catalyst 3750-X 24-Port PoE+ Switch, 435W, LAN Base

WS-C3750X-24P-L

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 3750-X WS-C3750X-24P-L is a stackable enterprise access switch for wired campus and branch networks. It suits wiring closets that need PoE+ for IP phones, Wi-Fi access points and IP cameras, where the Layer 2 LAN Base feature set is enough.

It provides 24 10/100/1000 PoE+ ports, a 160 Gbps switching fabric and a 65.5 mpps forwarding rate with two 10GbE uplinks. The default C3KX-PWR-715WAC power supply gives a 435W PoE budget, and the chassis has dual redundant modular power supply bays. Uplinks are added through optional hot-swappable network modules, with 4x GbE SFP, 2x 10GbE SFP+ or 2x 10GBASE-T options. This SKU ships with the LAN Base feature set, covering Layer 2 switching with up to 255 VLANs and 16 static routes.

StackWise Plus delivers 64 Gbps of stack throughput with up to nine switches per stack, and StackPower support lets stack members share power. A LAN Base switch stacks only with other 3750-X LAN Base switches. The 1RU chassis measures 4.45 x 44.5 x 46.0 cm.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Cisco StackWise Plus stacking with 64 Gbps throughput, local switching and up to nine stack members
- Cisco StackPower shares power across stack members for power redundancy
- Hot-swappable optional uplink network modules in 1G, 10G SFP+ and 10GBASE-T
- Dual redundant modular power supplies and fans
- MACsec (IEEE 802.1AE) hardware encryption on downlink ports
- Layer 2 threat defence with port security, DHCP snooping, dynamic ARP inspection and IP source guard
- 802.1X flexible authentication and Cisco TrustSec
- Cisco EnergyWise and Smart Operations including Smart Install and Auto Smartports
- QoS with eight egress queues per port and SRR scheduling

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Ports: 24 x 10/100/1000 PoE+ Ethernet
- Feature set: LAN Base
- Default power supply: C3KX-PWR-715WAC (715W AC)
- Available PoE power: 435W
- Uplinks: optional network modules (4x GbE SFP, 2x 10GbE SFP+, 2x 10GBASE-T or Service Module)
- Stacking: StackWise Plus, 64 Gbps, up to 9 switches per stack
- StackPower: supported, from software release 15.0(2)SE
- Switching fabric: 160 Gbps
- Forwarding rate: 65.5 mpps (with two 10GbE uplinks)
- DRAM: 256 MB
- Flash: 64 MB
- VLANs: 1005 total, 4K VLAN IDs
- Switched virtual interfaces: 1K
- Jumbo frame: 9216 bytes
- Unicast MAC addresses: 4K (Access), 6K (Default), 3K (Routing), 12K (VLAN template)
- Security ACEs: 2K (Access), 1K (Default/Routing/VLAN)
- Dimensions (H x W x D): 4.45 x 44.5 x 46.0 cm (1RU)
- Weight: 7.2 kg
- MTBF: 167,198 hours
- Operating temperature (AC PSU): -5 to +45 C up to 1500 m
- Relative humidity: 5% to 95%, non-condensing
- Typical power consumption: about 99 W with no PoE load

FAQs

Q: Which licence tier does this switch use?
A: WS-C3750X-24P-L runs the LAN Base feature set. It can be upgraded to IP Base or IP Services with Cisco IOS Software Activation licences.

Q: Can it be stacked with IP Base or IP Services switches?
A: No. A LAN Base 3750-X can only stack with other 3750-X LAN Base switches. Mixing feature sets in one stack is not supported.

Q: How much PoE does it provide?
A: With the default 715W AC power supply it provides a 435W PoE budget. A single 715W supply delivers 15.4W per port, while 30W PoE+ on every port needs one 1100W supply or two 715W supplies.

Q: Which uplink modules does it work with?
A: It accepts C3KX-NM-1G (4x GbE SFP), C3KX-NM-10G (2x 10GbE SFP+ or 4x SFP), C3KX-NM-10GT (2x 10GBASE-T) and the C3KX-SM-10G Service Module.

Q: Which power supplies are compatible?
A: The C3KX-PWR-350WAC, 715WAC, 1100WAC and 440WDC supplies are compatible. A second supply can be fitted for redundancy.
