• Cisco WS-C3650-24TS-E 24-port 1G switch with 4x1G SFP uplinks
1 1

Cisco

Cisco WS-C3650-24TS-E | Catalyst 3650 24-Port Gigabit Switch, 4x 1G SFP, IP Services

WS-C3650-24TS-E

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 3650 24-port Gigabit switch is a stackable, enterprise-class access-layer switch for campus, branch and remote office networks where wired and wireless are converged on one platform. It has integrated wireless controller capability and ships with the IP Services feature set for advanced Layer 3 routing.

This data-only model provides 24 10/100/1000 Ethernet ports and 4 fixed Gigabit SFP uplinks, with no PoE budget. Switching capacity is 92 Gbps with a forwarding rate of 41.66 Mpps, and optional StackWise-160 stacking adds 160 Gbps of stack bandwidth. It is powered by a 250 W AC supply (PWR-C2-250WAC), and the chassis has a second power supply slot for redundancy. IP Services is the highest of the three feature set tiers and is activated through right-to-use licensing on a single universal Cisco IOS image.

The SFP uplinks accept 1000BASE-T, 100BASE-FX, 1000BASE-SX/LX/LH/ZX/BX10, CWDM and DWDM SFP transceivers. Stacking is supported with other Catalyst 3650 switches running the same feature set.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Integrated wireless controller capability, supporting 25 access points and 1000 wireless clients per switch or stack
- Optional Cisco StackWise-160 stacking built on the Cisco UADP ASIC
- Field-replaceable redundant fans and power supplies, with a second power supply slot
- Single universal Cisco IOS image across all feature set levels
- Full IPv4 and IPv6 routing, multicast routing, modular QoS and Flexible NetFlow v9
- Advanced Layer 3 routing with OSPF, EIGRP, BGPv4, IS-ISv4 and PIM
- Energy-Efficient Ethernet (EEE) supported on ports

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Model: WS-C3650-24TS-E
- Ethernet ports: 24 x 10/100/1000 (data only, no PoE)
- Uplinks: 4 x Gigabit Ethernet SFP, fixed
- Feature set: IP Services
- Switching capacity: 92 Gbps
- Forwarding rate: 41.66 Mpps
- Stacking: optional StackWise-160, 160 Gbps
- DRAM: 4 GB
- Flash: 2 GB
- MAC addresses: 32,000
- IPv4 routes (ARP plus learned routes): 24,000
- VLAN IDs: 4,094
- Switched virtual interfaces: 1,000
- Jumbo frame: 9198 bytes
- Default power supply: 250 W AC (PWR-C2-250WAC)
- PSU input: 100-240 VAC, 50-60 Hz
- Maximum power consumption: 57.1 W at 100% traffic
- Form factor: 1 RU rack-mountable
- Dimensions (H x W x D): 4.4 x 44.5 x 44.8 cm
- Weight: 6.87 kg
- Operating temperature: -5 to +45 C up to 1500 m
- Storage temperature: -40 to 70 C
- Relative humidity: 5% to 96% noncondensing
- MTBF: 661,800 hours

FAQs

Q: Does this switch provide PoE?
A: No. The WS-C3650-24TS-E is a data-only model with no PoE budget. Devices that need PoE require a PoE-capable Catalyst 3650 variant or a separate injector.

Q: Which licence tier does this SKU include?
A: It ships with the IP Services feature set, the highest of the three tiers (LAN Base, IP Base, IP Services). Feature sets are activated through right-to-use licensing from the Cisco IOS CLI on one universal image.

Q: Can it be stacked with other Catalyst 3650 switches?
A: Yes, using optional StackWise-160 stacking at 160 Gbps. Every member of a stack must run the same feature set, and mixed LAN Base, IP Base and IP Services stacks are not supported.

Q: What power supply does it use, and can I add a second one?
A: It uses a 250 W AC supply (PWR-C2-250WAC) with 100-240 VAC input. The chassis has two power supply slots, so a second PWR-C2 series supply can be added for redundancy.

Q: What can be installed in the SFP uplink ports?
A: The 4 Gigabit SFP uplinks accept 1000BASE-T, 100BASE-FX, 1000BASE-SX/LX/LH/ZX/BX10, CWDM and DWDM SFP transceivers.
