• Cisco WS-C3560X-48T-S 48-port Gigabit Ethernet switch with black faceplate
1 1

Cisco

Cisco WS-C3560X-48T-S | Catalyst 3560-X 48-Port Gigabit Switch, IP Base, 350W

WS-C3560X-48T-S

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 3560-X is an enterprise-class Layer 3 access switch with 48 10/100/1000 Ethernet ports in a 1 RU standalone chassis. This data-only model carries the IP Base feature set, making it a fit for campus and branch access layers where gigabit density is needed without PoE, and where routed access, security and flexible uplinks matter.

It provides a 160 Gbps switching fabric and a forwarding rate of 101.2 mpps with two 10GbE uplinks, backed by 256 MB DRAM and 64 MB flash. The default power supply is a 350W AC unit, and a second power supply can be fitted for redundancy. The uplink slot accepts optional modules: 4x 1G SFP, 2x 10G SFP+, 2x 10GBASE-T, or the Service Module for NetFlow and MACsec.

IP Base covers baseline Layer 3 features including static routing, RIP, EIGRP stub and OSPF for routed access. Upgrading to IP Services adds full OSPF, EIGRP, BGPv4, IS-ISv4, PBR, PIM and VRF-Lite. The switch works with the Cisco XPS 2200 redundant power system and the C3KX rack-mount accessory kits. It is not stackable.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hot-swappable optional uplink modules for 1G SFP, 10G SFP+ or 10GBASE-T
- Modular power supplies and fans with optional second supply for redundancy
- IP Base Layer 3 routing with static routing, RIP, EIGRP stub and OSPF for routed access
- MACsec encryption and Flexible NetFlow when fitted with the Service Module
- 802.1X, flexible authentication, TrustSec, DHCP snooping, dynamic ARP inspection and IP source guard
- Cisco EnergyWise for power monitoring and management
- Smart Install, Auto Smartports and Smart Configuration for simpler deployment
- Out-of-band Ethernet management port plus USB Type-A and Type-B ports

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Ports: 48 x 10/100/1000 Ethernet (non-PoE)
- Feature set: IP Base
- Form factor: 1 RU standalone, non-stackable
- Default power supply: 350W AC (C3KX-PWR-350WAC), 100-240 VAC, 50-60 Hz
- PoE budget: none (data-only model)
- Uplink slot: optional C3KX-NM-1G, C3KX-NM-10G, C3KX-NM-10GT or C3KX-SM-10G Service Module
- Switching fabric: 160 Gbps
- Forwarding rate: 101.2 mpps (with two 10GbE uplinks)
- DRAM: 256 MB
- Flash: 64 MB
- VLANs: 1005 total, 4K VLAN IDs
- Switched Virtual Interfaces: 1K
- Jumbo frame: 9216 bytes
- Unicast MAC addresses: 4K / 6K / 3K / 12K (Access / Default / Routing / VLAN template)
- Unicast routes: 6K / 8K / 11K / 0 (Access / Default / Routing / VLAN template)
- Dimensions (H x W x D): 4.45 x 44.5 x 46.0 cm
- Weight: 7.3 kg
- MTBF: 186,778 hours
- Operating temperature: -5 to 45 C up to 1500 m, -5 to 40 C up to 3000 m
- Relative humidity: 5% to 95%, non-condensing
- Typical power consumption: 120 to 126 W depending on uplink module
- Compliance: UL60950-1, CE, FCC Part 15 Class A, AS/NZS CISPR22 Class A, RoHS 5, NEBS Level 3

FAQs

Q: Does this switch support PoE?
A: No. The WS-C3560X-48T-S is a data-only model with no PoE budget. PoE models are a separate variant in the 3560-X range.

Q: Which licence does it ship with, and can it be upgraded?
A: It ships with the IP Base feature set. It can be upgraded to IP Services with the C3560X-LIC= product activation key plus an upgrade licence. IP Services is needed for full OSPF, EIGRP, BGPv4, IS-ISv4, PBR, PIM and VRF-Lite.

Q: What uplink modules does it work with?
A: The uplink slot takes the C3KX-NM-1G (4x GbE SFP), C3KX-NM-10G (2x 10GbE SFP+), C3KX-NM-10GT (2x 10GBASE-T) and the C3KX-SM-10G Service Module for NetFlow and MACsec.

Q: Can I add power supply redundancy?
A: Yes. A second power supply can be fitted, with 715W AC, 1100W AC and 440W DC options available. The switch also works with the Cisco XPS 2200 redundant power system.

Q: Can it be stacked with other switches?
A: No. The 3560-X is a standalone switch. StackWise and StackPower apply to the Catalyst 3750-X only.
