• Cisco WS-C3560X-48PF-S 48-port PoE+ switch with modular uplinks
1 1

Cisco

Cisco WS-C3560X-48PF-S | Catalyst 3560-X 48-Port PoE+ Switch, 1100W, IP Base

WS-C3560X-48PF-S

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 3560-X is a standalone 1 RU enterprise access switch with 48 x 10/100/1000 PoE+ ports, built for campus and branch access layers. It suits deployments with PoE+ devices such as IP phones, Aironet wireless access points and IP cameras, and it supports routed access and MACsec security requirements.

This 48 port PoE+ model delivers up to 30W per port from a default 1100W AC power supply (C3KX-PWR-1100WAC), providing 800W of available PoE. It offers a 160 Gbps switching fabric and a forwarding rate of 101.2 mpps with two 10GbE uplinks. Optional hot-swappable uplink network modules add 4 x GbE SFP, 2 x 10GbE SFP+, 2 x 10GBASE-T or a Service Module with 2 x SFP+. It ships with the IP Base feature set, which can be upgraded to IP Services through a Cisco IOS Software Activation licence.

A second power supply bay allows redundancy or extra PoE budget, and the switch can be backed up by the Cisco XPS 2200 redundant power system. The 3560-X is standalone and does not support StackWise or StackPower.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- IEEE 802.3at PoE+ with up to 30W on all 48 ports in 1 RU
- Modular power supplies and fans with redundant power options
- Optional hot-swappable uplink network modules with GE or 10GE ports
- MACsec (IEEE 802.1AE) hardware-based encryption on downlink ports
- Cisco EnergyWise for power monitoring and management
- Cisco Smart Operations: Smart Install, Auto Smartports, Smart Configuration and Smart Troubleshooting
- Layer 3 routed access in IP Base: static, RIP, EIGRP stub and OSPF for routed access
- Advanced QoS with 8 egress queues per port and SRR scheduling
- Layer 2 threat defence including port security, DHCP snooping, DAI and IP source guard

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Ports: 48 x 10/100/1000 Ethernet PoE+
- PoE standard: IEEE 802.3at, up to 30W per port
- Default power supply: C3KX-PWR-1100WAC (1100W AC)
- Available PoE power: 800W
- Feature set: IP Base
- Uplinks: optional network modules (4 x GbE SFP, 2 x 10GbE SFP+, 2 x 10GBASE-T, or Service Module with 2 x SFP+)
- Switching fabric: 160 Gbps
- Forwarding rate: 101.2 mpps (with two 10GbE uplinks)
- DRAM: 256 MB
- Flash: 64 MB
- VLANs: 1005 total, 4K VLAN IDs
- Switched virtual interfaces: 1K
- Jumbo frame: 9216 bytes
- Form factor: 1 RU, standalone (not stackable)
- Dimensions (H x W x D): 4.45 x 44.5 x 49.5 cm (1.75 x 17.5 x 19.5 in)
- Weight: 7.5 kg (16.6 lb)
- MTBF: 149,594 hours
- Power supply input (1100W AC): 115-240 VAC, 50-60 Hz
- Operating temperature (AC supply): -5 to 45 C up to 1500 m; -5 to 40 C up to 3000 m
- Relative humidity: 5% to 95%, non-condensing

FAQs

Q: Which feature set does this switch ship with, and can it be upgraded?
A: It ships with the IP Base feature set. You can upgrade to IP Services with a Cisco IOS Software Activation licence (C3560X-48-S-E paper licence or L-C3560X-48-S-E e-licence). IP Services is required for full OSPF, EIGRP, BGPv4, IS-ISv4, PBR, PIM and VRF-Lite.

Q: How much PoE power does it provide?
A: The default C3KX-PWR-1100WAC power supply provides 800W of available PoE, with up to 30W per port under IEEE 802.3at. A second power supply bay allows redundancy or extra PoE budget.

Q: What uplink modules does it work with?
A: It accepts the C3KX-NM-1G (4 x GbE SFP), C3KX-NM-10G (2 x 10GbE SFP+ / SFP), C3KX-NM-10GT (2 x 10GBASE-T) and C3KX-SM-10G Service Module (2 x SFP+). The modules are hot-swappable.

Q: Which power supplies and redundant power options does it support?
A: It supports the C3KX-PWR-350WAC, -715WAC, -1100WAC and -440WDC power supplies, and the Cisco XPS 2200 can be used as a redundant power system.

Q: Can it be stacked with other switches?
A: No. The 3560-X is a standalone switch and does not support StackWise or StackPower.
