• Cisco WS-C3560X-48P-S 48-port PoE+ switch in rack
1 1

Cisco

Cisco WS-C3560X-48P-S | Catalyst 3560-X 48-Port PoE+ Switch, IP Base, 435W

WS-C3560X-48P-S

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 3560-X is a standalone 1 RU enterprise access switch built for campus wiring closets that need routed access, PoE+ and a choice of uplink speeds. This IP Base model suits networks powering IP phones, Wi-Fi access points and other PoE+ endpoints from a single switch.

It provides 48 10/100/1000 PoE+ ports, with up to 30W per port on supported devices. The default 715W AC power supply provides a 435W PoE budget, and the chassis supports a second power supply for redundancy. Switching capacity is 160 Gbps, with a forwarding rate of 101.2 mpps when fitted with two 10GbE uplinks. The IP Base feature set covers baseline Layer 3 routed access, including OSPF, and an upgrade to IP Services is available through Cisco IOS software activation.

The uplink network module slot accepts the C3KX-NM-1G, C3KX-NM-10G, C3KX-NM-10GT and C3KX-SM-10G modules, giving 1G SFP, 10G SFP+ or 10GBASE-T uplinks. Power supply options include the C3KX-PWR-350WAC, 715WAC, 1100WAC and 440WDC, as well as the XPS 2200 redundant power system.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- IEEE 802.3at PoE+ with up to 30W per port
- Hot-swappable uplink network modules for 1G or 10G connectivity
- Modular power supplies and fans with redundancy support
- MACsec hardware encryption on downlink ports
- IPv4 and IPv6 routing, multicast routing and hardware QoS
- Cisco EnergyWise for power monitoring and management
- Smart Operations tools: Smart Install, Auto Smartports and Smart Configuration
- Layer 2 protection: Port Security, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Ports: 48 x 10/100/1000 PoE+ (up to 30W per port)
- Feature set: IP Base
- Default power supply: 715W AC (C3KX-PWR-715WAC)
- Available PoE power (default PSU): 435W
- Uplinks: optional network modules (1G SFP, 10G SFP+, 10GBASE-T or service module)
- Switching fabric: 160 Gbps
- Forwarding rate: 101.2 mpps (with two 10GbE uplinks)
- DRAM: 256 MB
- Flash: 64 MB
- VLANs: 1005 total, 4K VLAN IDs
- Switched virtual interfaces: 1K
- Jumbo frame: 9216 bytes
- Form factor: 1 RU, standalone (non-stackable)
- Dimensions (H x W x D): 4.45 x 44.5 x 46.0 cm
- Weight: 7.4 kg
- MTBF: 149,594 hours
- AC input (715W PSU): 100-240 VAC, 50-60 Hz
- Operating temperature (AC PSU): -5 to +45 C up to 1500 m
- Relative humidity: 5% to 95%, noncondensing
- Management: USB Type-A and Type-B ports, out-of-band Ethernet port

FAQs

Q: Which licence tier does this switch ship with?
A: It ships with the IP Base feature set, which covers baseline Layer 3 routed access. An upgrade to IP Services is available through Cisco IOS software activation.

Q: How much PoE power does it provide?
A: With the default 715W AC power supply, the switch provides a 435W PoE budget. A second power supply can be added for redundancy.

Q: What is needed to deliver 30W on all 48 ports?
A: Delivering full 30W PoE+ on every port requires two 1100W power supplies, or one 1100W and one 715W supply. The 440W DC supply and the XPS 2200 are also supported.

Q: Which uplink modules work with it?
A: The switch accepts the C3KX-NM-1G, C3KX-NM-10G and C3KX-NM-10GT network modules, as well as the C3KX-SM-10G service module.

Q: Can this switch be stacked?
A: No. The Catalyst 3560-X is a standalone switch and does not support StackWise stacking.
