• Cisco WS-C2960X-48TS-LL in 3U rackmount chassis with honeycomb front panel
1 1

Cisco

Cisco WS-C2960X-48TS-LL | Catalyst 2960-X 48-Port Gigabit Switch, 2x SFP, LAN Lite

WS-C2960X-48TS-LL

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 2960-X 48-port Gigabit switch is a fixed-configuration Layer 2 access switch for enterprise campus and branch networks. It suits access-layer deployments that need basic managed Gigabit connectivity for non-PoE endpoints, with fibre or copper SFP uplinks back to the distribution layer.

This model provides 48 x 10/100/1000 Ethernet ports and 2 x 1G SFP uplink ports. It delivers 50 Gbps of forwarding bandwidth, 100 Gbps of switching bandwidth and a forwarding rate of 104.2 Mpps. It is a non-PoE model, so no PoE budget is available. It operates standalone only and does not support FlexStack-Plus or FlexStack-Extended stacking. It ships with the Cisco IOS LAN Lite feature set, which is tied to this SKU and cannot be upgraded to LAN Base or IP Lite. Optional term-based Cisco DNA Essentials licences enable Full Flexible NetFlow and Cisco DNA Center features.

The SFP uplinks accept a wide range of Cisco SFP modules. The switch is a 1U unit for 19-inch racks, with a fixed internal 100-240 VAC power supply and optional Cisco RPS 2300 external power redundancy.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Line-rate Gigabit access switching for enterprise campus and branch networks
- Cisco IOS management via CLI, SNMP, web UI, and RJ-45 or USB console access
- Security features including 802.1X, Port Security, BPDU Guard, DAI, IP Source Guard, ACLs, TACACS+/RADIUS and SSH/SNMPv3
- Enhanced QoS with up to eight egress queues per port, SRR scheduling and Auto-QoS
- Cisco Smart Install, Auto SmartPorts, AutoSecure, GOLD and Smart Call Home operations tools
- Energy efficiency with IEEE 802.3az EEE, Switch Hibernation Mode and Cisco EnergyWise
- Resiliency through Flex Links, RSTP/MSTP/PVRST+ and switch-port auto-recovery
- Supported by Cisco Prime Infrastructure, Network Plug and Play and Cisco DNA Center

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Ethernet ports: 48 x 10/100/1000
- Uplink ports: 2 x 1G SFP
- Software feature set: Cisco IOS LAN Lite
- PoE: None (non-PoE model)
- Stacking: Standalone only, no FlexStack-Plus or FlexStack-Extended
- Forwarding bandwidth: 50 Gbps
- Switching bandwidth: 100 Gbps
- Forwarding rate: 104.2 Mpps (64-byte packets)
- Flash memory: 64 MB
- DRAM: 256 MB
- CPU: APM86392 600 MHz dual core
- Console ports: USB Type B and RJ-45 Ethernet
- Management interface: 10/100 Mbps Ethernet (RJ-45)
- Maximum active VLANs: 64 (4096 VLAN IDs available)
- Unicast MAC addresses: 16,000
- Jumbo frame: 9216 bytes
- Input voltage: 100 to 240 VAC auto-ranging, 50 to 60 Hz
- Weighted average power consumption: 44.4 W
- Dimensions (H x D x W): 4.5 x 27.9 x 44.5 cm (1U)
- Weight: 4.0 kg
- Operating temperature: -5 to 45 C up to 1500 m
- MTBF: 476,560 hours

FAQs

Q: Does the LAN Lite feature set need a separate licence?
A: No. The LAN Lite feature set is tied to this SKU and cannot be upgraded to LAN Base or IP Lite. Optional Cisco DNA Essentials term licences add Full Flexible NetFlow and Cisco DNA Center features.

Q: Does this switch provide PoE?
A: No. This is a non-PoE model with no PoE budget. It suits endpoints that are powered separately.

Q: Can I stack this switch with others?
A: No. It operates standalone only and does not support FlexStack-Plus or FlexStack-Extended stacking modules.

Q: What can I fit in the SFP uplink ports?
A: The 2 x 1G SFP uplink ports accept a wide range of Cisco SFP modules for fibre or copper uplinks.

Q: Can it be powered redundantly?
A: It has a single fixed internal AC power supply, and the optional Cisco RPS 2300 (PWR-RPS2300) external redundant power system is supported.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

Manual

This product has a detailed PDF manual available. Open PDF manual in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.
