• Cisco WS-C2960X-48LPD-L 48-port PoE+ switch with 10G SFP+ uplinks
1 1

Cisco

Cisco WS-C2960X-48LPD-L | Catalyst 2960-X 48-Port PoE+ Switch, 370W, 2x 10G SFP+

WS-C2960X-48LPD-L

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 2960-X is a fixed-configuration, stackable Gigabit Ethernet access switch built for enterprise and branch access-layer deployments. This model suits sites that need PoE+ for IP phones, wireless access points and cameras, with 10G SFP+ uplinks and the option to stack.

It provides 48 10/100/1000 PoE+ ports and two fixed 10G SFP+ uplinks. The 370W PoE budget supports up to 12 ports at 30W (PoE+) or 24 ports at 15.4W (PoE). Forwarding bandwidth is 108 Gbps with 216 Gbps switching bandwidth and a forwarding rate of 130.9 Mpps for 64-byte packets. It supports up to 1023 active VLANs and jumbo frames to 9216 bytes. It runs the Cisco IOS LAN Base feature set, in a 1RU rack-mountable chassis.

FlexStack-Plus and FlexStack-Extended stacking are supported, using CAB-STK-E-0.5M, CAB-STK-E-1M or CAB-STK-E-3M cables with the FlexStack-Plus module. SFP and SFP+ modules listed in Cisco's Transceiver Compatibility matrix can be fitted to the uplink ports, and an optional external Cisco RPS 2300 provides power redundancy.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Fixed-configuration, stackable Gigabit Ethernet access switch
- PoE+ support with Perpetual PoE
- FlexStack-Plus and FlexStack-Extended stacking
- Layer 3 features including routed access (OSPF), static routing and RIP
- Management via web UI, Bluetooth, CLI, SNMP, and RJ-45 or USB console
- Supports Cisco Prime, Network Plug and Play and Cisco DNA Center
- Visibility with DNS-AS and Full (Flexible) NetFlow
- Cisco EnergyWise energy management included

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Ports: 48 x 10/100/1000 Ethernet PoE+
- Uplinks: 2 x 10G SFP+ fixed
- PoE budget: 370W
- PoE+ (802.3at): up to 12 ports at 30W
- PoE (802.3af): up to 24 ports at 15.4W
- Software image: Cisco IOS LAN Base
- Stacking: FlexStack-Plus and FlexStack-Extended capable
- Forwarding bandwidth: 108 Gbps
- Switching bandwidth: 216 Gbps
- Forwarding rate: 130.9 Mpps (64-byte packets)
- Flash memory: 128 MB
- DRAM: 512 MB
- Maximum active VLANs: 1023
- Jumbo frame: 9216 bytes
- Console ports: USB Type B and RJ-45 Ethernet
- Management interface: 10/100 Mbps Ethernet (RJ-45)
- Power input: 100 to 240 VAC auto-ranging, 50 to 60 Hz
- Dimensions (H x D x W): 4.5 x 36.8 x 44.5 cm
- Weight: 5.8 kg
- Operating temperature: -5 to 45 C (up to 1500 m)
- Mounting: 1RU rack-mountable

FAQs

Q: Which software feature set does this switch run?
A: The WS-C2960X-48LPD-L runs the Cisco IOS LAN Base feature set. It is the LAN Base variant of the 2960-X, not LAN Lite.

Q: How many PoE devices can it power at once?
A: It has a 370W PoE budget. That supports up to 12 ports at 30W (PoE+) or up to 24 ports at 15.4W (PoE), or a mix within the total budget.

Q: Can it be stacked with other switches?
A: Yes. It supports FlexStack-Plus and FlexStack-Extended stacking. FlexStack-Plus uses CAB-STK-E-0.5M, CAB-STK-E-1M or CAB-STK-E-3M cables with the FlexStack-Plus module.

Q: What can be fitted to the 10G SFP+ uplinks?
A: The two fixed uplinks accept SFP and SFP+ modules listed in Cisco's Transceiver Compatibility matrix.

Q: Can it use a redundant power supply?
A: Yes. It has one internal AC power supply and supports the optional external Cisco RPS 2300 for power redundancy.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

Manual

This product has a detailed PDF manual available. Open PDF manual in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.
